Quick Details
-
Max. Spindle Speed (r.p.m):
-
2400 r.p.m
-
Max. Weight of Workpiece(kg):
-
750
-
Spindle Bore(mm):
-
520
-
Width of bed (mm):
-
300 mm
-
Spindle Motor Power(kW):
-
5.5
-
Max. Turned Length (mm):
-
1500
-
Travel (X Axis)(mm):
-
750 mm
-
Travel (Z Axis)(mm):
-
230 mm
-
Place of Origin:
-
Shandong, China
-
Dimension(L*W*H):
-
2000*1020*1210
-
Brand Name:
-
Teast
-
Model Number:
-
CA6141
-
Voltage:
-
customized
-
Weight (KG):
-
1228
-
Name:
-
Metal Lathe Machine
-
After Warranty Service:
-
Spare parts
Quick Details
-
Type:
-
Horizontal
-
Max. Length of Workpiece (mm):
-
750
-
Year:
-
2020
-
Max. Spindle Speed (r.p.m):
-
2400 r.p.m
-
Max. Weight of Workpiece(kg):
-
750
-
Spindle Bore(mm):
-
520
-
Width of bed (mm):
-
300 mm
-
Spindle Motor Power(kW):
-
5.5
-
Max. Turned Length (mm):
-
1500
-
Travel (X Axis)(mm):
-
750 mm
-
Travel (Z Axis)(mm):
-
230 mm
-
Place of Origin:
-
Shandong, China
-
Dimension(L*W*H):
-
2000*1020*1210
-
Brand Name:
-
Teast
-
Model Number:
-
CA6141
-
Voltage:
-
customized
-
Weight (KG):
-
1228
-
Name:
-
Metal Lathe Machine
-
After Warranty Service:
-
Spare parts
Product Description
Specification
|
Product Model
|
CA6141
|
|
Max. Swing Over Bed
|
410mm
|
|
Max. Swing in Gap
|
640mm
|
|
Effective Gap Lathe
|
200mm
|
|
Max. Length of Workpiece
|
750/1000/1500mm
|
|
Width of bed
|
300mm
|
|
Max. workpiece weight
|
300KG
|
|
Max. through hole of spindle
|
48/52mm
|
|
Front taper of spindle hole
|
MT6
|
|
Spindle speeds series
|
Level 12
|
|
Spindle speed range
|
32-2000 rpm
|
|
Longitudinal feed of feed box
|
0.06-0.82 mm
|
|
Lateral feed of feed box
|
0.017-0.242 mm
|
|
Cross slide plate shape
|
240mm
|
|
Knife holder stroke
|
125mm
|
|
Top taper
|
MT4
|
|
Tailstock sleeve travel
|
1.50mm
|
|
Tailstock sleeve diameter
|
63mm
|
|
Main motor
|
3/4.5KW
|
|
Cooling pump power
|
0.09KW
|
|
Dimension
|
2000*1000*1210
|
|
Net weight/Gross weight
|
1228/1378
|
Packing & Delivery
Tengdong Machine Tool Co., Ltd. is a set of lathes, milling machines, drilling machines, planers, presses and other machine tool
equipment consisting mainly of modern production group production enterprises.
Company under the three production bases, an import and export foreign trade companies
equipment consisting mainly of modern production group production enterprises.
Company under the three production bases, an import and export foreign trade companies
FAQ
Q1: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
Q2.What is your minimum order quantity and warranty?
A:MOQ is one set, and warranty is one year.
Q3.How soon can I receive the goods?
A:Most of our products are in stock, and we will arrange shipment around a week after payment is completed.
Q4.Can I trust you?
A:Sure, we’re Alibaba Gold Suppliers , Alibaba Assessed Supplier , Alibaba Trade Assurance Supplier.
Q5.What is the package? Is it suitable for shipment?
A:Machine is by waterproof cloth to covered.And be packed by standard exported wooden case with steel foot.. It is very much strong for oversea transportation.
Q6.Are you manufacturer?
A: Yes, we are a manufacturer of machine tools,we have our own technical team, and about 100,000 sq.m workshop, welcome to visit us!
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
Q2.What is your minimum order quantity and warranty?
A:MOQ is one set, and warranty is one year.
Q3.How soon can I receive the goods?
A:Most of our products are in stock, and we will arrange shipment around a week after payment is completed.
Q4.Can I trust you?
A:Sure, we’re Alibaba Gold Suppliers , Alibaba Assessed Supplier , Alibaba Trade Assurance Supplier.
Q5.What is the package? Is it suitable for shipment?
A:Machine is by waterproof cloth to covered.And be packed by standard exported wooden case with steel foot.. It is very much strong for oversea transportation.
Q6.Are you manufacturer?
A: Yes, we are a manufacturer of machine tools,we have our own technical team, and about 100,000 sq.m workshop, welcome to visit us!
