1. More wider range of usage: we have made lots of improvement just according to the feedback of our customers and the improved machine can be more widely used in more production aspects.
- Product Details
- {{item.text}}
Quick Details
-
Ejector Force(kN):
-
53.1 kN
-
Theoretical Shot Volume(cm³):
-
491 cm³
-
Injection Rate (g/s):
-
447 g/s
-
Injection Weight (g):
-
447 g
-
Screw diameter (mm):
-
50 mm
-
Weight (KG):
-
6800
-
Place of Origin:
-
Jiangsu, China
-
Open Stroke(mm):
-
530 mm
-
Model Number:
-
SZ-2000A
-
Brand Name:
-
almaco
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
thermoplastic
-
Automatic:
-
YES
-
Screw L/D:
-
23.1
-
Injection pressure:
-
2150kg/cm2
-
Screw stroke:
-
250mm
-
Heating power:
-
16.6kw
-
Opening stroke:
-
500mm
-
Max daylight:
-
1030
-
Model:
-
SZ-2000A
-
Feature:
-
high quality
-
Certification:
-
TUV CE ISO
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
505mm
-
Distance between Tie Bars(Height)(mm):
-
505mm
-
Ejector Stroke(mm):
-
125 mm
-
Ejector Force(kN):
-
53.1 kN
-
Theoretical Shot Volume(cm³):
-
491 cm³
-
Injection Rate (g/s):
-
447 g/s
-
Injection Weight (g):
-
447 g
-
Screw diameter (mm):
-
50 mm
-
Weight (KG):
-
6800
-
Place of Origin:
-
Jiangsu, China
-
Open Stroke(mm):
-
530 mm
-
Model Number:
-
SZ-2000A
-
Brand Name:
-
almaco
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
thermoplastic
-
Automatic:
-
YES
-
Screw L/D:
-
23.1
-
Injection pressure:
-
2150kg/cm2
-
Screw stroke:
-
250mm
-
Heating power:
-
16.6kw
-
Opening stroke:
-
500mm
-
Max daylight:
-
1030
-
Model:
-
SZ-2000A
-
Feature:
-
high quality
-
Certification:
-
TUV CE ISO
Product Description
1. More wider range of usage: we have made lots of improvement just according to the feedback of our customers and the improved machine can be more widely used in more production aspects.
3.More choices for you and evem the only size for you: we can supply you the standard size of the machine and we can also design the special size of the machine as you require.
Specification
|
Screw diameter
|
mm
|
50
|
55
|
60
|
||
|
Screw L/D
|
--
|
23.1
|
21
|
19.3
|
||
|
Shot weight
|
gram
|
447
|
540
|
643
|
||
|
Injection capacity
|
cm3
|
491
|
594
|
707
|
||
|
Injection pressure
|
kg/cm2
|
2150
|
1750
|
1490
|
||
|
Screw stroke
|
mm
|
250
|
|
|
||
|
Screw torque
|
N.m
|
1510
|
|
|
||
|
Heating power
|
kw
|
16.6
|
|
|
||
|
Clamping force
|
ton
|
200
|
|
|
||
|
Opening stroke
|
mm
|
500
|
|
|
||
|
Mould height
|
mm
|
190-530
|
|
|
||
|
Max daylight
|
mm
|
1030
|
|
|
||
|
Space between tie bars
|
mm
|
505×505
|
|
|
||
|
Ejector force/stroke
|
ton/mm
|
5.31/125
|
|
|
||
|
Oil pump motor
|
kw
|
18.5
|
|
|
||
|
Machine size
|
m
|
5.9×1.5×2.0
|
|
|
||
|
Machine weight
|
ton
|
6.8
|
|
|
||
