Quick Details
-
Brand Name:
-
SUNYU
-
Place of Origin:
-
Shandong
-
Size:
-
1550*870*1600mm, 1550*870*1600mm
-
Controller:
-
15 tube controller
-
Battery:
-
48V/60V 20AH -50AH Lead-acid/lithium battery
-
Weight:
-
160kgs
-
Motor Power:
-
650W,800W,1200W
-
Tire:
-
300-8 vaccum tire
-
Loading capacity:
-
300kgs
-
Speed:
-
25-45km/h
-
Range:
-
50-100km
-
Color:
-
White ,Red Green Blue ,accept customized colors
Quick Details
-
Power:
-
501 - 800W
-
Voltage:
-
60V
-
Tire Size:
-
300-8
-
Brand Name:
-
SUNYU
-
Place of Origin:
-
Shandong
-
Size:
-
1550*870*1600mm, 1550*870*1600mm
-
Controller:
-
15 tube controller
-
Battery:
-
48V/60V 20AH -50AH Lead-acid/lithium battery
-
Weight:
-
160kgs
-
Motor Power:
-
650W,800W,1200W
-
Tire:
-
300-8 vaccum tire
-
Loading capacity:
-
300kgs
-
Speed:
-
25-45km/h
-
Range:
-
50-100km
-
Color:
-
White ,Red Green Blue ,accept customized colors
Specification
|
Basic information |
Vehicle Brand
|
Sunyu
|
|
|
|
|
||||||
|
|
Vehicle Type
|
mini Electric Bus
|
|
|
|
|
||||||
|
|
Body Structure
|
four wheel mini electric bus
|
|
|
|
|
||||||
|
|
Vehicle Model
|
SY-E2
|
|
|
|
|
||||||
|
|
Carryin
|
2 people
|
|
|
|
|
||||||
|
● mean YES； ○ mean Options；— mean NO
|
|
|
|
|
|
|
||||||
|
electric model :
|
|
A
|
B
|
C
|
D
|
E
|
||||||
|
Basic Specification |
Body size：L*W*H (mm)
|
1550×880×1600mm
|
|
|
|
|
||||||
|
|
Basket size
|
450*290*230mm
|
|
|
|
|
||||||
|
|
Climbing angle（ %）
|
≤ 40
|
|
|
|
|
||||||
|
|
Ground clearance (mm)
|
200
|
|
|
|
|
||||||
|
|
max speed（km/h）
|
40
|
|
|
|
|
||||||
|
|
Maximum range ( km )
|
55KM
|
60KM
|
55KM
|
70KM
|
100
|
||||||
|
|
Load Weight（kgs）
|
400kgs
|
|
|
|
|
||||||
|
Motor
|
Motor power (KW)
|
650W
|
|
|
|
|
||||||
|
|
Motor type
|
Brushless motor
|
|
|
|
|
||||||
|
|
Controller
|
15 tube controller
|
|
|
|
|
||||||
|
Battery
|
Battery type
|
MF battery
|
|
Lithium battery
|
|
|
||||||
|
|
Battery capacity
|
20AH
|
35AH
|
20AH
|
32AH
|
50AH
|
||||||
|
|
Number of battery
|
5
|
5
|
1
|
1
|
1
|
||||||
|
|
Normal Charge Times（hr）
|
6-8
|
|
|
|
|
||||||
|
|
Input Voltage （VAC）
|
65-565V
|
|
|
|
|
||||||
|
Wheel& Brake
|
Front brake type
|
hand brake+foot brake+brake button+parking brake
|
|
|
|
|
||||||
|
|
Wheel hub type
|
100-90R8 Aluminium
|
|
|
|
|
||||||
|
|
Shock absorption type
|
Quadruple hydraulic spring shock absorption
|
|
|
|
|
||||||
|
other specification
|
Auto power off fully charge
|
●
|
|
|
|
|
||||||
|
|
one key start
|
●
|
|
|
|
|
||||||
|
|
Lock the car to prevent theft
|
●
|
|
|
|
|
||||||
|
|
Vehicle alarm
|
●
|
|
|
|
|
||||||
|
|
Steering wheel material
|
ABS
|
|
|
|
|
||||||
|
|
LCD panel
|
●
|
|
|
|
|
||||||
|
|
Real-time status
|
●
|
|
|
|
|
||||||
|
|
Seat material
|
PU seat
|
|
|
|
|
||||||
|
|
Steering lamp
|
●
|
|
|
|
|
||||||
|
|
LED Combination headlight
|
●
|
|
|
|
|
||||||
|
|
Light combination switch
|
●
|
|
|
|
|
||||||
|
|
Front wheel basket
|
●
|
|
|
|
|
||||||
|
|
800KW/1200W motor
|
option
|
|
|
|
|
||||||
|
|
Rain Curtain
|
option
|
|
|
|
|
||||||
Product Description
Other electric scooter to be choosed ,Meet your requirement
