Quick Details
-
Warranty:
-
2 Years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Car Model:
-
All motorhome ac, bus/truck/motorhome/caravan
-
Engine:
-
3.5 AWD, 3.5
-
Cooling capacity:
-
12000BTU
-
Cooling power:
-
2500W/3000W/3500W
-
Refrigerant:
-
R410a
-
Packaging Details:
-
Standard carton package
-
Certification:
-
CE, Rohs, CB
Quick Details
-
OE NO.:
-
01
-
Reference NO.:
-
08089789
-
Size:
-
667*497*96
-
Warranty:
-
2 Years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Car Model:
-
All motorhome ac, bus/truck/motorhome/caravan
-
Engine:
-
3.5 AWD, 3.5
-
Cooling capacity:
-
12000BTU
-
Cooling power:
-
2500W/3000W/3500W
-
Refrigerant:
-
R410a
-
Packaging Details:
-
Standard carton package
-
Certification:
-
CE, Rohs, CB
Product Details
Product Paramenters
|
Model Name
|
|
|
|
PMDV-08
|
PMDV-12
|
|||
|
Function
|
|
|
|
Cooling & Heating
|
Cooling & Heating
|
|||
|
Capacity
|
Cooling
|
|
W
|
2500
|
3500
|
|||
|
|
Heating
|
|
W
|
2200
|
3200
|
|||
|
EER/COP
|
|
|
W/W
|
2.33/2.24
|
2.75/2.71
|
|||
|
Power Supply
|
|
|
ph,V,Hz
|
1ph,220V,50-60hz
|
1ph,220V,50-60hz
|
|||
|
Power Input
|
Cooling
|
|
W
|
1070
|
1270
|
|||
|
|
Heating
|
|
W
|
980
|
1180
|
|||
|
Cooling Current
|
|
|
A
|
6.6
|
8
|
|||
|
Refrigerant
|
|
|
|
R410A
|
R410A
|
|||
|
Indoor Unit
|
Airflow Volume
|
|
m³/h
|
340/280/220/190
|
380/320/260/230
|
|||
|
|
Sound Pressure Level
|
|
dB(A)(SH/H/M/L)
|
53/48/43/38
|
55/49/44/39
|
|||
|
|
Outline Dimension
|
W×H×D
|
mm
|
667×497×96
|
667×497×96
|
|||
|
|
Net Weight
|
|
kg
|
5.5
|
5.5
|
|||
|
Outdoor Unit
|
Sound Pressure Level
|
|
dB(A)
|
65/55
|
65/55
|
|||
|
|
Outline Dimension
|
W×H×D
|
mm
|
1018×650×294
|
1018×650×294
|
|||
|
|
Net Weight
|
|
kg
|
41
|
41
|
|||
|
|
Pakage Dimension
|
W×H×D
|
mm
|
1100×715×435
|
1100×715×435
|
|||
|
|
Gross Weight
|
|
kg
|
53
|
55
|
|||
|
Loading Quantity
|
|
20`GP
|
sets
|
80
|
80
|
|||
|
|
|
40`GP
|
sets
|
160
|
160
|
|||
|
|
|
40`HQ
|
sets
|
160
|
160
|
|||
