- Product Details
- {{item.text}}
Quick Details
-
Blade Speed (m/min):
-
100X150
-
Weight (KG):
-
68
-
Motor Power (kw):
-
0.55
-
Name:
-
SGSK mini saw machine BS-115 band saw machine
-
Circular @90°:
-
115mm(4.5")
-
Rectangular @90°:
-
100*150mm(4"x6")
-
Blade size:
-
13*0.6*1538mm
-
Motor power:
-
375W 1/2HP(3PH), 550W 3/4HP(1PH)
-
Drive:
-
V-belt
-
Circular @45°:
-
100mm(4")
-
Packing size:
-
97*46*46cm
-
N.W./G.W.:
-
68/72kg
-
Power (kW):
-
0.375
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SGSK
-
Cutting Capacity (mm):
-
115
-
Blade Speed (m/min):
-
100X150
-
Weight (KG):
-
68
-
Motor Power (kw):
-
0.55
-
Name:
-
SGSK mini saw machine BS-115 band saw machine
-
Circular @90°:
-
115mm(4.5")
-
Rectangular @90°:
-
100*150mm(4"x6")
-
Blade size:
-
13*0.6*1538mm
-
Motor power:
-
375W 1/2HP(3PH), 550W 3/4HP(1PH)
-
Drive:
-
V-belt
-
Circular @45°:
-
100mm(4")
-
Packing size:
-
97*46*46cm
-
N.W./G.W.:
-
68/72kg
-
Power (kW):
-
0.375
SGSK mini saw machine BS-115 band saw machine
Products Description
Details Display
Features:
1. This band saw features a belt drive and 3-speed conversion.
2. Light-weight design, suitable for field and construction site application
3. The maximum processing capacity is 115 mm (4.5”). 4. The saw bow can rotate from 0° to 45°, and can be used vertically and horizontally.
4. It features quick and fixed clamping and is equipped with a block feeder (with fixed sawing length)
5. With a sizing device, machine will stop automatically after sawing materials
Main technical parameter
1. This band saw features a belt drive and 3-speed conversion.
2. Light-weight design, suitable for field and construction site application
3. The maximum processing capacity is 115 mm (4.5”). 4. The saw bow can rotate from 0° to 45°, and can be used vertically and horizontally.
4. It features quick and fixed clamping and is equipped with a block feeder (with fixed sawing length)
5. With a sizing device, machine will stop automatically after sawing materials
Main technical parameter
|
Model
|
|
BS-115
|
|
|
Capacity
|
Circular @90°
|
115mm(4.5”)
|
|
|
|
Rectangular @90°
|
100X150mm(4”x6”)
|
|
|
|
Circular @45°
|
100mm(4”)
|
|
|
|
Rectangular @45°
|
60x100mm(2.4”x4”)
|
|
|
Blade speed
|
@60Hz
|
24,35,61MPM
|
|
|
|
@50Hz
|
20,29,50MPM
|
|
|
Blade size
|
|
13x0.6x1538mm
|
|
|
Motor power
|
|
375W 1/2HP(3PH), 550W 3/4HP(1PH)
|
|
|
Drive
|
|
V-belt
|
|
|
Packing size
|
|
97x46x46cm
|
|
|
N.W./G.W.
|
|
68/72kg
|
|
