1. high purity quartz tube.
2. Working temperature: 1250°C soft temperature: 1730°C.
3. Excellence in vision and chemistry Manifestation.
4. No surface coating and infectious agent.
5. Health care and environmental protection.
6. All different sizes can be completed according to the customer's needs.
7. CE. RoHs SGS approved.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
ZGN0406
-
Color:
-
transparent
-
Size:
-
customize
-
Material:
-
SIO2>99.99%
-
Density:
-
2.2g/cm3
-
Work Temperature:
-
1150 ℃
-
Hardness:
-
Morse 6.5
-
Melting point:
-
1732 ℃
-
Strain point:
-
1100 ℃
-
Annealing point:
-
1180 ℃
-
Package:
-
Carton+Bubble Film+Woodem Cases
-
Length:
-
customize
Quick Details
-
Type:
-
Clear Quartz Pipe
-
Application:
-
Semiconductors/optics
-
Outside Diameter:
-
customize
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
ZGN0406
-
Color:
-
transparent
-
Size:
-
customize
-
Material:
-
SIO2>99.99%
-
Density:
-
2.2g/cm3
-
Work Temperature:
-
1150 ℃
-
Hardness:
-
Morse 6.5
-
Melting point:
-
1732 ℃
-
Strain point:
-
1100 ℃
-
Annealing point:
-
1180 ℃
-
Package:
-
Carton+Bubble Film+Woodem Cases
-
Length:
-
customize
Video Description
Size and design: Accept customization according to different diameters, thicknesses, lengths or send your drawings.
High temperature resistant quartz glass tube can be used for a long time at 1100 degrees Celsius, widely used in point light source, semiconductor, optical communication, military, chemical, electric power and other fields, can be customized glass tube of various sizes.
Product Description
Detail pictures
Product Parameters
|
Density
|
2.2(g/cm3)
|
|
Transformation point
|
1200℃
|
|
Temperatures for long periods of time
|
1200 °C to 1300 °C
|
|
Temperature over a short period of time
|
1500 ℃
|
|
Light transmittance
|
80%-95%
|
|
Melting temperature
|
1750 ~ 1800 ℃
|
|
Shear modulus
|
31000Mpa
|
|
Softening point
|
1730℃
|
|
Thermal conductivity (20 °C)
|
1.4w/m ℃
|
|
Specific heat (20 °C)
|
660J/kg℃
|
|
Recommend Products
|
|
|
|
|
||||
|
Production process
|
|
|
|
|
||||
Product Considerations
1. Do not operate at temperatures that exceed the maximum working temperature of quartz for a long time.
Otherwise, the product will be deformed Crystallize or soften. 2. Clean the quartz products before operating in a high temperature environment. The product is first soaked in 10% hydrofluoric acid and then washed with high-purity water or alcohol. The operator should wear thin gloves and direct contact with the quartz glass with their hands is inhibited. 3. It is wise to extend the life and heat resistance of quartz products by continuous use at high temperatures Environment.
Otherwise, interval use will shorten the product life. 4. Try to avoid contact with alkaline substances (such as sodium silicate,asbestos, potassium and sodium compounds, etc.)Quartz glass products are made of acidic materials at high temperatures. Otherwise the anti-crystallization
properties of the product will be:Greatly reduced. Factory support drawing to sample customization Buyer's note Due to the wide variety of quartz products, our prices are not necessarily the actual prices. Different types and sizes of quartz have different prices. We can only take a picture of the buyer for reference, and then you give us the specifications, we will give you a quote. For example, the longer the length of a quartz rod, the more expensive it is. Of course, the price also depends on the
quantity.The larger the quantity, the cheaper the price. Contact the seller for details.
Otherwise, the product will be deformed Crystallize or soften. 2. Clean the quartz products before operating in a high temperature environment. The product is first soaked in 10% hydrofluoric acid and then washed with high-purity water or alcohol. The operator should wear thin gloves and direct contact with the quartz glass with their hands is inhibited. 3. It is wise to extend the life and heat resistance of quartz products by continuous use at high temperatures Environment.
Otherwise, interval use will shorten the product life. 4. Try to avoid contact with alkaline substances (such as sodium silicate,asbestos, potassium and sodium compounds, etc.)Quartz glass products are made of acidic materials at high temperatures. Otherwise the anti-crystallization
properties of the product will be:Greatly reduced. Factory support drawing to sample customization Buyer's note Due to the wide variety of quartz products, our prices are not necessarily the actual prices. Different types and sizes of quartz have different prices. We can only take a picture of the buyer for reference, and then you give us the specifications, we will give you a quote. For example, the longer the length of a quartz rod, the more expensive it is. Of course, the price also depends on the
quantity.The larger the quantity, the cheaper the price. Contact the seller for details.
Packing&Delivery
Our business philosophy is quality survival, development reputation. Products are widely sold all over the world, such as the United States, Germany, France, Italy, Australia, Canada, the United Kingdom, Spain, Sweden, Mexico, Argentina, Chile, Russia, India, Japan and many other countries.
Packaging for Customized Quartz Glass Tube:
Inner: 1piece / Bubble paper. Plastic air cushion film. Foam material.
Outer: Shipping Carton /Wooden case /According to customers' requirement.
Packaging for Customized Quartz Glass Tube:
Inner: 1piece / Bubble paper. Plastic air cushion film. Foam material.
Outer: Shipping Carton /Wooden case /According to customers' requirement.
