Quick Details
-
Brand Name:
-
ZR
-
Model Number:
-
Customized
-
Product name:
-
Tool cabinet; metal storage cabinet
-
Drawers Quantity:
-
Customized
-
Structure:
-
cabinet, drawer, steel handle
-
Drawers Type:
-
5/6/7 Drawers
-
Lock:
-
IntelligentCombination Lock
-
Caster Wheels:
-
5'' Noiseless Double Ball Bearing Rubber Wheels,4PCS
-
Product Size:
-
W800*D500*1000(mm)
-
Packing Size:
-
W840*D540*H890(mm)
-
Application Industry:
-
Factory workshop
-
Application:
-
Mechanical processing enterprises assembly process, storage
Quick Details
-
Warranty:
-
1 year
-
Color:
-
Cabinet body dark gray, drawer red
-
Place of Origin:
-
shandong
-
Brand Name:
-
ZR
-
Model Number:
-
Customized
-
Product name:
-
Tool cabinet; metal storage cabinet
-
Drawers Quantity:
-
Customized
-
Structure:
-
cabinet, drawer, steel handle
-
Drawers Type:
-
5/6/7 Drawers
-
Lock:
-
IntelligentCombination Lock
-
Caster Wheels:
-
5'' Noiseless Double Ball Bearing Rubber Wheels,4PCS
-
Product Size:
-
W800*D500*1000(mm)
-
Packing Size:
-
W840*D540*H890(mm)
-
Application Industry:
-
Factory workshop
-
Application:
-
Mechanical processing enterprises assembly process, storage
Product Description
|
ZRC-702-1 Tool Cart Tool Cabinet Specification：
|
|
Material
: High quality cold rolled steel plate
Thickness
: Back Hang Plate 1.2mm; Cabinet Body Door 1.0mm;Drawers 0.8mm
5 Drawers Size
:
W529×D440×H90(mm) (2PCS)
W529×D440×H140(mm) (2PCS)
W529×D440×H258(mm) (1PCS)
Right Door Size: W388×H740(mm)
Brief Introduction:
The tool cabinet is equipped with a back hanging plate (left two-thirds of the punching square hole, can hang hook,
right one-third of the punching louver hole, can hang material boxes); The top of the back hanging plate is equipped with two drawing clips. The left side of the cabinet is equipped with five drawers, with three sections of beaded sliding rails, bearing≤35kg, and controlled by central lock. The drawers are equipped with full-width aluminum alloy handle belt and self-locking. Right side with a door, with a layer of adjustable laminate. The right side of the cabinet is equipped with a stainless steel handle for easy pushing and pulling. The bottom is equipped with 4PCS 4'' polyurethane casters(2PCS Rigid Caster+2PCS Swivel Plate Caster With brake). Production Process: The products are made by laser cutting, CNC bending, two welding, pickling, degreasing,phosphating, plastic spraying, baking and other processes. |
|
TC-BR-501 Tool Cart Tool Cabinet Specification：
|
|
Material
: High quality cold rolled steel plate
Thickness
: Cabinet Body Door 1.0mm;Drawers 0.8-1.0mm Product
Size:W800*D500*H1000+360(mm) Five Drawers Sizes As Below:
W600*D450*H75=2PCS,each drawer bearing capacity 40kgs(uniform weight)
W600*D450*H110=2PCS,each drawer bearing capacity 40kgs (uniform weight) W600*D450*H320=1PCS,bearing capacity 80 kg (uniform weight) Colo r: As Photo Showing,Blue+Dark Lock : Intelligent Combination Lock Caster Wheels : 5'' Noiseless Double Ball Bearing TPR Wheels,2PCS Fixed Type+2PCS Swivel With Brake Finishing :Electrostatic Coating
Brief Introduction About The Five Drawers
:
The first and second drawers can store tools and measuring tools, and thIrd and fourth drawers are equipped with vertical and horizontal inserts, can store tool head, blade, drill, tap, the space is adjustable. The fifth drawer is equipped with knife handle covers. The upper part of the cabinet is equipped with a holder of knife handle cover. Product Package: Carton Board+Bubble Film+Pallet |
|
The tool cabinet is used for machining, and the multi-function tool cart is convenient for storage and storage
|
|
Installation/Color/Tread Hardness/Wheel Core Customization
|
|
