Quick Details
-
Control System Brand:
-
PA
-
Cutting Area:
-
3000 * 1500 / 2500 * 1300mm
-
Cutting Thickness:
-
6-22mm plywood, 4mm metal
-
Control Software:
-
TSD laser cutting software
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TSD LASER
-
Weight (KG):
-
2000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
-
Laser type:
-
High power axial flow CO2 laser generator
-
Laser power:
-
1000w
-
Cutting precision:
-
±0.05mm
-
Transmission system:
-
Ball screw & linear guide
-
Controlling system:
-
PMAC motion card
-
Optical system:
-
Semi-optical
-
Moving structure:
-
Grantry
-
Driving system:
-
3 Axial servo motor
-
Overall dimension:
-
3000*2300*1800mm(L*W*H)
Quick Details
-
Laser Type:
-
CO2
-
Cutting Speed:
-
over 60m/h for 18mm plywood cutting
-
Cooling Mode:
-
WATER COOLING
-
Control System Brand:
-
PA
-
Cutting Area:
-
3000 * 1500 / 2500 * 1300mm
-
Cutting Thickness:
-
6-22mm plywood, 4mm metal
-
Control Software:
-
TSD laser cutting software
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TSD LASER
-
Weight (KG):
-
2000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
-
Laser type:
-
High power axial flow CO2 laser generator
-
Laser power:
-
1000w
-
Cutting precision:
-
±0.05mm
-
Transmission system:
-
Ball screw & linear guide
-
Controlling system:
-
PMAC motion card
-
Optical system:
-
Semi-optical
-
Moving structure:
-
Grantry
-
Driving system:
-
3 Axial servo motor
-
Overall dimension:
-
3000*2300*1800mm(L*W*H)
Products Description
Product Paramenters
|
Model No.
|
TSD-LC400-1218
|
|
Laser type
|
CO2 Sealed Laser Tube
|
|
Transmission Syetem
|
Imported Ball Screw & Linear Guide
|
|
Control System
|
Movement Control Card
|
|
Positioning Precision
|
±0.05mm
|
|
Cutting Thickness
|
0.45mm , 0.71mm ,1.05mm...etc
|
|
Cutting Depth
|
6-25mm
|
|
Chiller System
|
Water Cooling
|
|
Covering Area
|
4200*4000mm
|
|
Applicable Material
|
Plywood,MDF Board , Acrylic and steel Sheet...etc
|
|
Applicable industry
|
It's widely used in Printing,Packing,Mould,advertising industries
|
|
Assistant Equipment
|
It's widely used in Printing,Packing,Mould,advertising industries
|
|
More detail information
|
Why Choose Us
We are professional dies machine manufacturer:
1.We only production CO2 laser die cutting machine and its supporting die blade bending machine blade bending machine.
2. CE certificate, Reasonable price, machine stable, Experienced & Responsible QC that you can rely on.
1.We only production CO2 laser die cutting machine and its supporting die blade bending machine blade bending machine.
2. CE certificate, Reasonable price, machine stable, Experienced & Responsible QC that you can rely on.
3. We have exported our machine to Indonesia, Kosovo, Egypt, Sri Lanka, India, Philippines, Bengal, Vietnam, Kuwait,Algeria....etc.
4. Adequate supply capacity ( 50 sets / month ), Punctual delivery time(2-3 Weeks) .
5. Home market: Guangdong, Jiangsu, Zhejiang, Fujian, Hunan, Jiangxi, Shandong, Sichuan, Henan, Shanxi, Shanxi, Beijing,
Shanghai,Hebei, Inner Mongolia, Guang xi, HK ... Etc.
6. Our affiliates in the country: East Division, Office of Hebei, Hangzhou Office, Office of Fujian
