Quick Details
-
Model Number:
-
DC-A48
-
Name:
-
48ci filling high pressure air gas paintball tank
-
Model number:
-
DC-A48
-
Material:
-
AA6061
-
Application:
-
Paintball
-
Water Capacity:
-
0.8L
-
Working Pressure:
-
207bar
-
Test Pressure:
-
310 bar
-
Thread:
-
5/8''-18UNF
-
Outside Diameter:
-
91.2mm
-
Certificate:
-
TPED ISO7866
Quick Details
-
Type:
-
paintball gas cylinder
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
DCEC
-
Model Number:
-
DC-A48
-
Name:
-
48ci filling high pressure air gas paintball tank
-
Model number:
-
DC-A48
-
Material:
-
AA6061
-
Application:
-
Paintball
-
Water Capacity:
-
0.8L
-
Working Pressure:
-
207bar
-
Test Pressure:
-
310 bar
-
Thread:
-
5/8''-18UNF
-
Outside Diameter:
-
91.2mm
-
Certificate:
-
TPED ISO7866
CO2 SYSTEM
|
name
|
working pressure
(psi / bar)
|
external diameter(in / mm)
|
height(in / mm)
|
weight(lbs / kgs)
|
water volume(cu in / cc)
|
thread gage(in / mm)
|
|
DC-A09
(9oz)
|
1800 / 124
|
2.126 / 54
|
9.37 / 238
|
0.73 / 0.33
|
23.15 / 380
|
0.625-18UNF-2B
|
|
DC-A12 (12oz)
|
1800 / 124
|
2.50 / 63,8
|
9.37 / 238
|
1.1 / 0.5
|
31 / 508
|
0.625-18UNF-2B
|
|
DC-A16 (16oz)
|
1800 / 124
|
3.189 / 81
|
7.68/195
|
1.37 / 0.62
|
40 / 657
|
0.625-18UNF-2B
|
|
DC-A20 (20oz)
|
1800 / 124
|
3.189 / 81
|
9.25/235
|
1.63 / 0.74
|
48.8 / 800
|
0.625-18UNF-2B
|
|
DC-A24 (24oz)
|
1800 / 124
|
3.189 / 81
|
10.83/275
|
1.89 /0.86
|
57.6 / 943
|
0.625-18UNF-2B
|
AIR SYSTEM
|
name
|
working pressure
(psi / bar) |
external diameter(in / mm)
|
height(in / mm)
|
weight(lbs / kgs)
|
water volume(cu in / cc)
|
thread gage(in / mm)
|
|
DC-B6
(13ci) |
3000 / 207
|
1.97 / 50
|
7.09 / 180
|
0.7 /0.32
|
13/ 197
|
0.625-18UNF-2B
|
|
DC-A26
(26ci) |
3000 / 207
|
3.59 / 91.2
|
5.90 / 150
|
1.76 / 0.8
|
26 / 390
|
0.625-18UNF-2B
|
|
DC-A48 (48ci)
|
3000 / 207
|
3.59 / 91.2
|
8.54 / 215
|
2.56 / 1.15
|
48 / 787
|
0.625-18UNF-2B
|
|
DC-A62
(62ci) |
3000 / 207
|
3.59 / 91.2
|
10.4 / 265
|
2.97 / 1.4
|
62 /990
|
0.625-18UNF-2B
|
The 6061-T6 aluminum alloy tank is refilled with carbon dioxide at a pressure of 1,800 PSI and tested at 3,000PSI. Air system of the cylinder is refilled with air at a pressure of 3,000 PSI and tested at 4,500 PSI. Each cylinder is 100% hydraulic tested and manufactured in accordance with TPED ISO7866 standard to assure the quality. We also offer valve attached service.
DCEC, founded in 1962, has been in the Aluminum Alloy business for more than 5 decades, nearly half a century.
We manufacture varieties of Aluminium bottles for purpose, including of chemical, gas, water bottle, essential oils, and so on.
We acquired ISO 9001 approval in 2003.
DCEC, moreover, devoted to develop high pressure cylinder for the markets Paintball, Aquarium, Beverage, and etc, wishes to continue its leading way on aluminum high pressure cylinders.
We have acquired the approval certificates TPED 2010/35/EU mark issued for European market.
The certificate of Surveillance of the applicant's In-house inspection service is also an guarantee for DCEC to manufacture the higher quality products.
