Product Name
|
Automatic Facial Napkin Paper Folding Machine
|
|
Model
|
SE-V
|
|
Post-paper machine
|
Standard 2, can be added according to customer requirements (hydraulic price extra)
|
|
Maximum diameter of base paper
|
1500mm
|
|
Inner diameter of raw paper core
|
3 inches (≈ ∮76mm)
|
|
Raw paper weight
|
12~16 g/m2 (2-ply), 18~22 g/m2 (1-ply) wood pulp paper.
|
|
Folded Size
|
175-210mm range customized according to customer requirements
|
|
Folding speed
|
≤105 m/min (design speed 120 m/min)
|
|
Sorting speed
|
7-18 articles/minute
|
|
Fan power
|
22KW (this power is the data of 7-row machine)
|
|
total power
|
36KW (this power is the data of 7-row machine)
|
|
Power supply type
|
Three-phase four-wire 380V 50Hz
|
|
machine noise
|
≤80dB (extension noise greater than 80dB, need to be placed independently)
|
|
air supply
|
0.5-0.8 MPa
|
|
gas consumption
|
120-160L/min
|
|
Product Name
|
Automatic Napkin Tissue Paper Cutting Machine
|
|
Model
|
SE-358
|
|
Raw material specifications
|
Width 45-110mm adjustable, thickness 25-150mm adjustable
|
|
Production capacity
|
60-360 cuts/minute (speed varies according to cut-off length)
|
|
Cutting length
|
Freely settable (within adjustable range)
|
|
Circular knife size
|
Φ610mm
|
|
Power supply
|
Three-phase four-wire 380V 50Hz 10KW
|
|
Air Requirements
|
0.5Mpa-0.8Mpa
|
|
Gas Consumption
|
100-160L/H
|
|
Dimension
|
L2550*W1520*H2000mm
|
|
Weight
|
2600kg
|
|
Product Name
|
Automatic Facial Tissue Box Carton Packing Sealing Machine
|
|
Model
|
OR-100B
|
|
Paper quality of carton
|
300-400g/m3
|
|
Maximum packing specification
|
L240mm×W120mm×H100mm
|
|
Packing speed
|
30-100boxes/minute
|
|
Hot melt machine power
|
2.50KW
|
|
Motor power
|
3.50KW
|
|
Total power
|
6.00KW
|
|
Power supply type
|
3phase 4wire 380V 50Hz
|
|
Machine noise
|
≤80dB
|
|
Air supply
|
0.5-0.8 Mpa
|
|
Air consumption
|
120-160L/min
|
|
Main machine Outline dimensions
|
L3250×W1650×H1800mm
|
|
Conveying mechanism Outline dimensions
|
L4000×W660×H1200mm
|
|
Machine weight
|
1500Kg
|
