- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Haifeng
-
Model Number:
-
HF-120GF
-
Speed:
-
1500RPM
-
Product Name:
-
High Performance With Certification 120KW Diesel Generator
-
Starting method:
-
24V DC Start Battery
-
Cooling method:
-
Closed Cycle Water-cooled
-
Generator Type:
-
Silent.Open.Trailer
-
Emergency stope:
-
automatic
-
Exciter:
-
brushless, AVR
-
Insulation class:
-
H degree
-
Protection class:
-
IP22
-
connecting type:
-
Three phase and four lines
-
Certification:
-
CE
Quick Details
-
Rated Voltage:
-
400/230V
-
Rated Current:
-
216A
-
Frequency:
-
50HZ
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Haifeng
-
Model Number:
-
HF-120GF
-
Speed:
-
1500RPM
-
Product Name:
-
High Performance With Certification 120KW Diesel Generator
-
Starting method:
-
24V DC Start Battery
-
Cooling method:
-
Closed Cycle Water-cooled
-
Generator Type:
-
Silent.Open.Trailer
-
Emergency stope:
-
automatic
-
Exciter:
-
brushless, AVR
-
Insulation class:
-
H degree
-
Protection class:
-
IP22
-
connecting type:
-
Three phase and four lines
-
Certification:
-
CE
|
Genset specification
|
|
|
|
|
||||
|
Genset Model
|
|
HF-120GF
|
|
|
||||
|
Prime Power(50HZ)
|
|
120KW/150KVA
|
|
|
||||
|
Frequency/Speed
|
|
50Hz/1500rpm
|
|
|
||||
|
Standard Voltage
|
|
230V/400V
|
|
|
||||
|
Rated Current
|
|
216A
|
|
|
||||
|
Overall Dimensions
|
|
2300*830*1250 (MM)
|
|
|
||||
|
Net Weight
|
|
1600 (KG)
|
|
|
||||
|
Phases
|
|
Three phases, four wires
|
|
|
||||
|
Engine Specification General Performance
|
|
|
|
|
||||
|
Manufacturer
|
|
Cummins Engine Co., Ltd.
|
|
|
||||
|
Engine Model
|
|
6BTAA5.9-G2
|
|
|
||||
|
Engine Type
|
|
4 stroke, V-type, 6-cylinder
|
|
|
||||
|
Engine Speed
|
|
1500 rpm
|
|
|
||||
|
Power
|
|
130KW
|
|
|
||||
|
Standby Power
|
|
Electric
|
|
|
||||
|
Air Intake Way
|
|
Turbo charged & intercooled (air to air)
|
|
|
||||
|
Displacement
|
|
7.25L
|
|
|
||||
|
Cylinder Bore * Stroke
|
|
102mm × 120mm
|
|
|
||||
|
Compression Ratio
|
|
17.5:1
|
|
|
||||
CONTROLLER
Soundproof 120
kw 150kva
Self Start Diesel Generator
Made in China
DIESIEL ENGINES
Soundproof 120
kw 150kva
Self Start Diesel Generator
Made in China
Made in China
ALTERNATOR
Soundproof 120
kw 150kva
Self Start Diesel Generator
Made in China
Made in China
