Quick Details
-
Brand Name:
-
SUPERSTAR
-
Model Number:
-
S8800B
-
Type:
-
Oral Therapy Equipments & Accessories
-
Name:
-
dental equipment S8800B
-
Certificate:
-
ISO
-
Product name:
-
nitrous oxide system
-
Usage:
-
N2O inhalation for sedation
-
Gas source:
-
O2,N2O
-
Voltage:
-
-220V±22V
-
Color:
-
White
-
Application:
-
Dental Area
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Free spare parts
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUPERSTAR
-
Model Number:
-
S8800B
-
Type:
-
Oral Therapy Equipments & Accessories
-
Name:
-
dental equipment S8800B
-
Certificate:
-
ISO
-
Product name:
-
nitrous oxide system
-
Usage:
-
N2O inhalation for sedation
-
Gas source:
-
O2,N2O
-
Voltage:
-
-220V±22V
-
Color:
-
White
-
Application:
-
Dental Area
S8800B n2o/nitrous oxide gas cylinder cartridges
Application:
The N2O Sedation System makes a good performance in gastrointestinal endoscope department, obstetrics department, dentistry department and other departments. From high to low acuity, simple to complex cases, pediatric to geriatric patients, Perlong Medical N2O Sedation Systems offer you the choices you need in ventilation, monitoring and technique. what’s more, our expertise in anesthesia delivery and ventilation is based on rich 23 -year history of developing anesthesia solutions that meet your needs. Good performance based on High S ecurity, H igh A ccuracy, H igh S tability and accurate monitoring.
Trust Points
l Simplicity: easy to use, easy to move with 4 wheels .
l Choice: adapt the equipment to your patients and procedures freely
l Designed and manufactured by Perlong Medical with over 2 3 years experience in this area.
l Flexible configurations to suit your needs.
l International standard and advanced technology suitable for wide range use.
l Compact interface and big screen give you better operating experience.
l Over 2,000 units installed in the world.
Features
l TFT LCD screen displays the V entilation parameters, A larming information and W aveform.
l Integration breathing circuit design , ensure easy operating and keep tidy.
l Multiple parameters monitoring interface, make every parameter clear, let users know the patient conditions in all aspects .
l Multiple Ventilation mode, suitable for different clinical need.
l Electronic control mixed gas blender, high precision adjustment.
l Built-in concentration monitoring system, real-time monitoring of airway pressure.
Safety
l Three level alarming system, visual and sound alarm information.
l With lots of alarming, reminding and protection functions.
l Advanced power management control technology.
l With built-in backup power source, when outside power source goes off, back-up power source starts to work.
Specifications
|
Ventilation modes: |
Continuous gas supply or On-demand gas supply Rapid oxygen supply Manual |
|
Oxygen concentration |
30%-100% |
|
N2O concentration |
0%-70% |
|
Continuous flow |
0-30L/min |
|
Manual ventilation flow |
0-30L/min |
|
Rapid oxygen flow |
25L/min-75L/min |
|
Monitoring parameters |
|
|
Oxygen concentration |
30%-100% |
|
Airway pressure |
0-60cmH2O |
|
Flow |
0-30L/min |
|
Graphical display: |
|
|
P-T(pressure – time) |
|
|
Size Wooden case packing size: L 700 *W 800 *H 420 mm , GW: 40 KG ; NW: 20 KG Wooden case packing size: L 1100 *W 160 *H 195 mm , GW: 6.7 KG ; NW: 2 KG
Alarm and protection |
|
|
The AC power failure alarm |
P ower failure or no connection |
|
Internal battery backup low voltage alarm |
< 11.3 ± 0.3V |
|
High oxygen concentration alarm Low oxygen concentration alarm |
31 %-100% 30 %-99% |
|
High Airway pressure alarm Pressure limit Emergency air input |
5 cmH2O- 60 cmH2O 60cmH2O When machine doesn ’ t work |
|
N2O Closure function |
When oxygen pressure ≤ 200kPa |
|
Low gas source input pressure |
Pressure ≤ 200kPa |
|
Working conditions |
|
|
Gas source |
O2,N2O |
|
Pressure |
280kPa-600kPa |
|
Voltage |
-220V± 22V |
|
Power frequency |
50 Hz± 1Hz |
|
Input power |
60 VA |
|
|
|
