Quick Details
-
L.O. Frequency:
-
1838MHz
-
Material:
-
Aluminum
-
Factory:
-
Anhui Bowei Electronics Technology Co,Ltd
-
color:
-
as picture
-
function:
-
receiving ground signal
-
work with:
-
antenna and power supply
-
Packing:
-
standard export carton(100pcs/CTN)
-
Product name:
-
mmds lnb
Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
BWEI
-
Model Number:
-
BW-MMDS
-
L.O. Frequency:
-
1838MHz
-
Material:
-
Aluminum
-
Factory:
-
Anhui Bowei Electronics Technology Co,Ltd
-
color:
-
as picture
-
function:
-
receiving ground signal
-
work with:
-
antenna and power supply
-
Packing:
-
standard export carton(100pcs/CTN)
-
Product name:
-
mmds lnb
Description
BoWei MMDS Down converter
( Frequency can be Customized based on Customers' requirement）
OEM & ODM available
Product Image
Specification
|
Model Number
|
BW-MMDS
|
|
Input Frequency
|
2500 - 2700 MHz
(1900-2100MHz; 2100-2300MHz; 2700-2900MHz option)
|
|
Local Frequency
|
1838MHz,option 1998MHz; 2033MHz; 2030MHz; 2278MHz; 2388MHz; 480MHz
(more than 200 frequencies can be customized)
|
|
Circuit board
|
Single sided board
|
|
L.O. Stability
|
≤ ±30KHz
|
|
Noise Figure
|
2.5dB@24dB, 1.8dB@32dB, 1.4dB@36dB
|
|
Conversion Gain
|
24dB±1.5dB, 32dB±1.5dB, 36dB±1.5dB
|
|
Gain Flatness
|
≤ 0.2 dB/CHANNEL
|
|
Image Rejection
|
≥ 50dB
|
|
VSWR
|
1.5 : 1
|
|
IF Rejection
|
≥ 80dB
|
|
PCS Rejection
|
≥ 100dB
|
|
WCS Rejection
|
≥ 50dB
|
|
3 order intermodulation
|
≤ - 50dB
|
|
L.O. Leakage Antenna Port
|
≤ - 85dB
|
|
L.O. Leakage IF-Port
|
≤ - 50dB
|
|
L.O. Phase Noise
|
-80dBc@100Hz offset, -92dBc@1kHz offset, -93dBc@10kHz offset
-95dBc@100kHz offset, -120dBc@1MHz offset
|
|
Output P1dB
|
+14dBm (typical)
|
|
Gain Flatness Over Entire Range
|
≤ ±1.5dB
|
|
IF Output Impedance
|
75Ω
|
|
DC Current Consumption
|
≤ 200mA
|
|
DC Input Voltage
|
14V-24V
|
|
Spurious in IF Band
|
≤ -100dBm
|
|
Opearating Temperature
|
-40℃ to +70℃
|
|
Input Type
|
BT280: Intergrated Dipole Antenna
|
|
Lightning Protection
|
Meets IEEE Standard
|
|
100% Hermetic
|
Sealed
|
