Quick Details
-
Injection pressure:
-
700kg/cm2
-
Opening stroke:
-
250-550mm
-
Tie-bars space:
-
500*580mm
-
Dimension(L*W*H):
-
2500*1600*3600mm
-
Clamping force:
-
130T
-
Shot volume:
-
165g
-
Pump pressure:
-
21Mpa
-
Injection Rate:
-
30g/s
-
Injection Weight:
-
165g
-
Power(W):
-
12KW
Quick Details
-
Injection Weight (g):
-
165 g
-
Screw diameter (mm):
-
150 mm
-
Place of Origin:
-
Guangdong, China
-
Injection pressure:
-
700kg/cm2
-
Opening stroke:
-
250-550mm
-
Tie-bars space:
-
500*580mm
-
Dimension(L*W*H):
-
2500*1600*3600mm
-
Clamping force:
-
130T
-
Shot volume:
-
165g
-
Pump pressure:
-
21Mpa
-
Injection Rate:
-
30g/s
-
Injection Weight:
-
165g
-
Power(W):
-
12KW
Horizontal Liquid Silicone Rubber (LSR) injection molding machine
D irect pressure mould opening and closing system, horizontal injection structure, it can adjust the mould faster, and control the position more precisely. I t is more suitable for producing the LSR parts which can be automatically remo ved from the mould.
T he main feature of the horizontal LSR molding machine:
A. N ewly-optimized integrated all-in-one design.
B. Meet multiple requirements on the automatic manufacturing technique for LSR products.
C. S horter the mould closing and opening time, improve the production efficiency.
D. R emote control function.
E. M ulti-section mould closing and opening and injection, speed adjusting stepless.
|
ITEM |
DESCRIPTION |
UNIT |
TYM-W4040 |
TYM-W4545 |
TYM-W5050 |
TYM-W5555 |
|
Injection Unit |
Shot Volume |
g |
165 |
165 |
300 |
300 |
|
Injection Rate |
g/s |
30 |
30 |
30 |
30 |
|
|
Injection Pressure |
Kg/cm2 |
200 |
200 |
200 |
200 |
|
|
Clamping Unit |
Clamping Force |
T |
120 |
130 |
150 |
160 |
|
Opening Stroke |
mm |
215-615 |
215-615 |
215-615 |
215-615 |
|
|
Tie-Bars Space |
mm |
400*400 |
450*450 |
500*500 |
550*550 |
|
|
Ejection Force |
T |
4.3 |
4.3 |
4.3 |
4.3 |
|
|
Ejection Stroke |
mm |
150 |
150 |
150 |
150 |
|
|
Pump Pressure |
Mpa |
21 |
21 |
21 |
21 |
|
|
Others |
Motor Power |
KW |
12.1 |
12.1 |
12.1 |
12.1 |
|
Machine Weight |
T |
2.8 |
3.5 |
4.1 |
4.9 |
|
|
Machine Dimension |
m |
4.1*1.5*1.95 |
4.1*1.6*2.0 |
4.1*1.6*2.3 |
4.2*1.6*2.4 |
