Semi automatic perfume laundry detergent Hand Sanitizer flat bottle cover lid self adhesive labeler labelling machines

Semi automatic perfume laundry detergent Hand Sanitizer flat bottle cover lid self adhesive labeler labelling machines

FOB Reference Price: Get Latest Price

≥1 Sets

US $500

≥2 Sets

US $400

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Jiangsu

Brand Name:: BOTTLING

Dimension(L*W*H):: 650mm*450mm*800mm

Weight:: 36 KG

Product name:: Semi auto square bottle self adhesive labeling machine

Labeling speed:: 20~50pcs/min

Bottle type:: Square Bottle

Labeling type:: One side or double side

Label material:: Transparent Label Or Sticker Label

Label roll core outer diameter:: 250mm

Label roll core inner diameter:: 75mm

Labeling accuracy:: ±1mm

Option 1:: Date coding device

Option 2:: Photoelectric detection for transparent label

Quick Details

Application:: Food, Beverage, Commodity, Chemical

Packaging Material:: Wood

Voltage:: Customized

Place of Origin:: Jiangsu

Brand Name:: BOTTLING

Dimension(L*W*H):: 650mm*450mm*800mm

Weight:: 36 KG

Product name:: Semi auto square bottle self adhesive labeling machine

Labeling speed:: 20~50pcs/min

Bottle type:: Square Bottle

Labeling type:: One side or double side

Label material:: Transparent Label Or Sticker Label

Label roll core outer diameter:: 250mm

Label roll core inner diameter:: 75mm

Labeling accuracy:: ±1mm

Option 1:: Date coding device

Option 2:: Photoelectric detection for transparent label

Products Description

All models of our semi automatic self-adhesive labeling machine

We have so many models to choose, so please tell me your requirements, then we can recommend the most suitable one for you, like the bottle photos, labeling speed, how many labels on one bottle, semi auto or automatic etc. please contact us in Alibaba or WhatSapp, let's start to provide help for you.

Semi auto square bottle self adhesive pressing labeling machine

Principle: Worker load bottles manually on bottle loading position, then press labeling rack down to bottle surface, then machine will press the label on bottle surface, labeling, pressing can be done at the same time; High labeling quality, no bubble, no decline; Machine have a range to be adjusted for different size bottle. Characters: 1, Applicable for glass bottle and PET bottles in flat shape. Machine need special order if the bottle is in particular shapes 2, Coder can be added if need Parameters: Machine Size: 650*450*850mm Output Speed: 20-50pcs/min Bottle diameter range (mm): 10-120mm Suitable Label Height: 15-60mm Suitable label Length: 15-120mm Labeling precision: ±1mm Labeling roll inner diameter≥ 75mm Labeling roll outer diameter≤φ250mm Weight: 36kg Power Supply: 220W

Semi auto 360 degree rotating self adhesive sticker labeling machine

With 360 degrees rotating roll method for flat labeling, make a mold fixed the product on the machine, then 360 degree rotating and labeling to achieve high precision labeling effect. Ideal suitable for polygonal shape product for labeling, Such as: Three sides labeling Four sides shape bottle Hexagon shape bottle Can be based on the customer's products, change the product of the mold, to achieve this irregular product labeling. With adjustable height stroke function, different height products, do not have to repeatedly replace the rule; It is specially used for all kinds of card labeling. It has high accuracy and no bubbles on the surface of various plastic sheets. It has automatic product identification function and automatically activates different labeling heads according to different products.

1) Change the labeling mechanism, can be applied to the uneven surface labeling, such as prism surface, circular surface labeling and so on. 2) By change the mold, can labeling irregular production. 3) Widely used in daily chemical, bio-medical, food, stationery supplies, mechanical hardware and other industries.

1. Germany Sick and Italy Data logic of self-adhesive label sensor. (standard model) 2. Germany Sick and LEUZE sensor not only can use for self-adhesive label, but also can use for transparent label. (price calculated separately). Panasonic PLC, Simple operation, do not need high-quality technical workers, easy to get started. Other languages available: such as: Spanish, Arabic, French. and so on. The inside of machine to keep dry, use longer. it connect electric and air compressor. working pressure: 0.3-0.6 MPA

Scope of application: Applicable labels: self-adhesive labels, self-adhesive films, electronic supervision codes, barcodes, etc. Applicable products: flat shape objects, the arc, the circumferential surface, concave, convex, or other surface attached to the label of the product; such as: Shampoo flat bottle, packaging box, caps, plastic shell and so on. Application examples: cardboard labeling, acrylic film, large plastic film, ceramic sheet film, etc.

SPECIFICATIONS
Labeling accuracy	±0.5mm (excluding products, labels, error)	Labeling speed	15--35 pcs/min (related to the product and label size)
Apply the product size	Length: 20-200mm Width: 20-150mm Thickness: 20-120 (Can be customized)	Apply label size	Length:15-100 mm; Width: 15-110 mm (Can be customized)
Applicable to the power supply	220V/50HZ (Need to add a voltage converter, according to the local voltage of different country)	Apply labels inside diameter	￠76mm
Apply labels outside diameter	￠240mm	Voltage	220V
Power consumption	330W	Air pressure	0.3---0.6Mpa
Net size (lengthwidth height)	Machine size: 850410720mm Packing size: 950780900mm	Weight	About 70Kg

Semi auto flat surface bottle/cap self adhesive labeling machine

Basic uses 1, Apply rolling labeling method to realize labeling in square bottle, multi-sided bottle, Polygonal product for one round labeling, such as cosmetic honey square bottle, cosmetic square bottle labeling and so on. 2, Changing the mold can be applied to product labeling of different specifications, etc. 3, Optional ribbon printer or inkjet printer to print the production date and batch number on the label to realize the integration of coding and labeling. Scope of application ◆ Applicable labels: self-adhesive labels, self-adhesive films, electronic supervision codes, barcodes, etc.; ◆ Applicable products: products that require square bottles and multi-edge product labels; ◆ Application industry: widely used in cosmetics, food, toys, daily chemicals, electronics, medicine, glue and seam agent and other industries; ◆ Application examples: labeling of honey, cosmetics, food, etc. Work process: Core working principle: The sensor detects that the product is in place or the foot is stepped on to signal that the product is in place, and the suction head sucking the label drops the label and overwrites the label, and then returns to the original position to absorb the next label, and wait for the next labeling signal. The attaching action is complete. Operation process: put the product -> judge in place (equipment detection control or manual control) -> label and relabel (automatically realized by the equipment) -> take out the labeled product. Technical parameters: (the following are the technical parameters of the standard model, other special requirements and functions can be customized) * Labeling accuracy: ±0.5mm (excluding product and label errors); * Labeling speed: 20～30 pieces/minute (related to product size); * Applicable product size: length: 20mm～100mm width: 20mm～280mm thickness: 0.2mm～60mm * Applicable label size: length: 15mm～100mm width: 15mm～130mm * Overall size: about 950mm×410mm×950mm (length×width×height); * Applicable power supply: 220V/50HZ; * The weight of machine: about 50Kg. * Applicable label inner diameter: Ø76mm Applicable label outer diameter: Ø 300mm * Power: 400w

Semi auto flat surface product self adhesive pressing labeling machine

Application: *For all kinds of flat/slightly arc surface labeling, such as flat bottle, cosmetics boxes, plastic cap labeling, etc. *Date printer can be added to print production date,batch lot and expiry date while labeling. *Widely used in food, cosmetic, chemical, pharmaceutical and other industries. *Support customization.

Control System: Japan Panasonic control system , with high stability and extremely low failure rate Operation System: Color touch screen , directly visual interface easy operation , with Chinese and English available Detection System: Using German LEUZE/ltalian Datalogic label sensor and Japanese Panasonic product sensor , which are sensitive to label and product , thus ensure high accuracy and stable labeling performance . Alarm Function: The machine will give an alarm when problem occur ,such as label spill , label broken , or other malfunctions Machine Material: The machine and spare parts all use material stain-less steel and anodized senior aluminum alloy , with high corrosion resistance and never rust . Voltage Transformer: Equip with a voltage transformer to adapt to local voltage

Parameter:		Data
Label Specification	adhesive sticker, transparent or opaque
Labeling Tolerance	±0.5mm
Capacity(pcs/min)	15 ~ 30
Suit bottle size(mm)	L:20~200 W:20~150 H:0.2~120;Can be customized
Suit label size(mm)	L: 15-100; W(H): 15-110
Machine Size(LWH)	≈830430820 (mm)
Pack Size(LWH)	≈880500830 (mm)
Voltage	220V/50(60)HZ;Can be customized
Power	330W
N.W (KG)	≈45.0
G.W(KG)	≈67.5
Label Roll	ID: Ø76mm;OD:≤240mm
Air Supply	0.4~0.6Mpa

Desktop flat surface self adhesive sticker labeling machine

It is suitable for labeling flat plane bottes and cartons, such as PET bottle, plastic bottles, glass bottle, metal bottles and paper boxes. Widely used in cosmetics, beverages, food, medicine and other industries, greatly improving productivity and labeling quality. Control panel> Simple Operation Panel (The English operation panel make it easy to test and use the machine,the label separating speed is adjustable. And can set the delay time of label separating.The beside two knobs can control the labeling speed annd conveyor speed as your need) Senior electric eye control system> Automatic imported fiber amplifier, automatic induction product labeling, simple and intelligent operation, ensuring the accuracy of labeling. Coneveyor belt> The width of the conveyor belt can be adjusted according to your container's size. And the width can be also customized if it exceeds the standard range. Labeling belt> Labeling quality, using standard of spring cover belt with long service life, labeling smooth, flat labeling, no wrinkles, no bubbles, improve packaging quality. Color ribbon coding machine> This machine can be euipped with a date coder, wihch can help you shorten the production process.It makes labeling and printing at one machine (optional). Accessories> All the accessories will be packaged with the machine, which are used to install the machine and some parts are aged for replacement after long-term use.

Voltage	220V/110V 50Hz/60Hz
Power	1000W
Labeling speed	10-40 meters/min
Labeling accuracy	± 1mm
Applicable label size	length: unlimited; width: 10-100mm
Applicable product size	length: unlimited; width: 20-200mm, height: 0.1-200mm
Applicable label roll inner diameter	Ф 76mm
Application label roll outer diameter	Ф 300mm
Conveyor width	200mm
PVC belt speed	5-40 meter/min
Distance from conveyor to floor	320mm±20mm (adjustable)

Desktop round bottle self adhesive sticker labeling machine

1.Equipment composition: Electrical cabinet, Conveyor, Roll label device, Brush label device, labeling engine, Operation system and control system; 2. Equipment function characteristics: (1) Control system：PLC control system, with high stable operation and extremely low failure rate; (2) Operation system：Touch screen, with Chinese and English language, rich with help function and fault display function,easy operation; (3) Check system：Check label and bottle sensor, Desktop check label position, stable and convenient don’t have much higher requirement for the worker skill; (4) Alarm function : such as label spill, label broken or other malfunction during machine working all will alarm and stop working. (5) Machine Material：The machine and spare parts use material stainless steel and anodized senior aluminum alloy,with high corrosion resistance and never rust; 3. Working process: 1 Worker put bottle on conveyor and delivery to labeling engine one by one; 2 When sensor check bottle, send signal to PLC, PLC received the signal deal with information first, then output signal to servo motor driver, driven by the drive motor send label. 3 The brush label device past label on bottle one side first, then bottle rolling around in the roll label device, brush label on bottle body for around, labeling finish.

Model	KP-40
Accuracy	±1mm
Speed(for 500ml bottle)	80-100pcs/min
Label Height	15-150mm
Label Length	25-300mm
Bottle height	25-350mm
Bottle diameter	<100mm
Accuracy	± 1mm (according to the bottle)
Label Roll	75--350mm
Power	AC110V/220V 50/60HZ 1000W
Dimension	1270X1000X780mm
Weight	130kg

Semi auto round bottle self adhesive sticker labeling machine

Principle: Worker load bottles manually on bottle loading position, then press labeling rack down to bottle surface, then labeling roll will rotate and leave the label to bottle surface, labeling, pressing can be done at the same time; High labeling quality, no bubble, no decline; Machine have a range to be adjusted for different size bottle. Characters: ■ Applicable for glass bottle and PET bottles in round shape. Machine need special order if the bottle is in particular shapes ■ Coder can be added if need Parameters: ■ Machine Size: 650(L)×450(W)×550(H)mm ■ Output Speed: 20-50pcs/min ■ Bottle diameter range (mm): 10-150mm ■ Suitable Label Height: 15-120mm ■ Suitable label Length: 15-315mm ■ Labeling precision: ±1mm ■ Labeling roll inner diameter: 76mm ■ Labeling roll outer diameter: 250mm ■ Weight: 35kg ■ Power Supply: 110V 0.12KW 50/60HZ

There are 4 kinds of labeling machines matching with 4 kinds of labels, Self-adhesive(sticker), sleeve label, OPP label, paper label, which kind of label is on your bottle?

4 kinds of labels

Round bottle adhesive labeling machine

Square bottle adhesive labeling machine

Bottle Sleeve labeling machine

OPP hot glue labeling machine

Cold glue paper labeling machine

company profile

ZhangJiaGang City BOTTLING MACHINERY Co.,Ltd. is located in Zhangjiagang city which is core of beverage machinery producer collection in China. Integrated the industry advantages and its own development in R&D, production, sales, after sales service,
BOTTLING MACHINERY is ready to serve more and more customers with our full range products and best service.BOTTLING MACHINERY is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.

We are the supplier who can design and manufacture for all kinds beverage production plant (pure drinking water, mineral water,carbonated drinks, juice, tea and beer, etc.)

Customer's service:
1. ZhangJiaGang City BOTTLING MACHINERY Co.,Ltd. can provide turn-key project for you, we can design the beverage factory plan according to your idea.
2. BOTTLING MACHINERY company have professional design team, our engineers can draw bottle samples and flow chart of workshop for you .
3. BOTTLING MACHINERY company can give you the best quotation for all kinds of beverage production, as long as you tell us which kind of drink you want to produce, what is your capacity(how many bottles one hour) what is you bottle material, pet or glass bottle or can, etc.

After service:
1. We send our engineers to your factory to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the goods shipping to you:
a. Machines layout drawing.
b. Electricity diagram.
c. Machine certificate.
d. General manual book/maintenance book.
3. After one year guarantee, the seller provides payable spare parts and technician's VISITING maintenance service.

Packing&Delivery of BOTTLING

1. Our machines are packed by wooden case. 2. The delivery date of this machine is within 10-25 days after payment.

FAQ

Q:Are you a manufacturer or trade company? A:We are a manufacturer in beverage bottling machine field more than 10 years, located at Leyu town, ZhangJiaGang, 2 hours from Shanghai, We will pick you up from Shanghai Pudong Airport to visit our factory. Q:Do you have any certification? A:SGS,ISO,CE etc Q:What about the delivery time? A:Usually 20-30 Working days for most kinds of machines Q:What about the machine’s capacity? A:1000 - 20000 bottles per hour based on 500ml bottle. Q:The after-sale service A:12 months warranty.

We can solve basic questions by telephone, email, whatsapp, wechat and video call. Engineer will go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines. Operating manuals will be sent with machines or by email. We also have overseas service center Q:If our bottle size changes, can we just do some adjustment on machine according to our new bottle? A:Yes. Maybe you just need some spare little parts to change. Q: If I want to purchase the machine, what information do I need to tell you? A:a. What kind beverage you want to produce? b. bottle volume? 250ml, 330ml, 500ml, 750ml, etc.? c. Producing capacity requirement? How many bottles per hour? d.Raw water analysis report . e.Voltage and altitude. Q:What kinds of product you supply? A: Drink water/juice/carbonated drink filling line for bottle or can. 5 gallon/20L bottle water filling line. Water treatment system. Bottle blowing molding machine.
