Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-SCI-EVO-3600&6200
-
Input Voltage:
-
24V/48V
-
Output Voltage:
-
110V/120V/220V/230V
-
Output Current:
-
15.7A/27A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
100*300*400
-
Certificate:
-
CE TUV ROHS
-
Warranty:
-
2 Years, 2 years
-
Weight:
-
9kg/10kg
-
Product name:
-
hybrid solar inverter
-
RATED POWER:
-
3600W/6200W
-
Wave form:
-
pure sine wave inverter
-
Communication interface:
-
WIFI
-
Nominal Output Voltage:
-
220/230/240VAC
-
Maximum Charging Current:
-
120A
-
Frequency:
-
50Hz/60HZ Auto
-
Efficiency:
-
98%
-
Application:
-
Home and appliance
Quick Details
-
Output Type:
-
DUAL, Three Phase
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
98%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-SCI-EVO-3600&6200
-
Input Voltage:
-
24V/48V
-
Output Voltage:
-
110V/120V/220V/230V
-
Output Current:
-
15.7A/27A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
100*300*400
-
Certificate:
-
CE TUV ROHS
-
Warranty:
-
2 Years, 2 years
-
Weight:
-
9kg/10kg
-
Product name:
-
hybrid solar inverter
-
RATED POWER:
-
3600W/6200W
-
Wave form:
-
pure sine wave inverter
-
Communication interface:
-
WIFI
-
Nominal Output Voltage:
-
220/230/240VAC
-
Maximum Charging Current:
-
120A
-
Frequency:
-
50Hz/60HZ Auto
-
Efficiency:
-
98%
-
Application:
-
Home and appliance
We have been in the solar energy industry for 14 years, and our products cover solar inverters, solar panels, solar panels, solar charge controllers, etc. We are a provider of solar energy solutions. For more detailed information, please contact me!
Products Description
Dual output function description:
The main and secondary outputs are used in normal condition. But in the following two conditions, the main output is disconnected
and only the secondary output is retained:
- when there is no solar power input and mains power input;
-when the battery voltage is lower than 44V (the minimum can be set to 41V, and the maximum can be set to 46V
The main and secondary outputs are used in normal condition. But in the following two conditions, the main output is disconnected
and only the secondary output is retained:
- when there is no solar power input and mains power input;
-when the battery voltage is lower than 44V (the minimum can be set to 41V, and the maximum can be set to 46V
|
Model
|
SCI-EVO-4200
|
SCI-EVO-6200
|
||
|
Rated Power
|
4200W
|
6200W
|
||
|
Maximum PV Input Power
|
6200W
|
6500W
|
||
|
Dimension: D x W x H (mm)
|
420*350*110mm
|
450*350*110mm
|
||
|
Net Weight (kgs)
|
9
|
10
|
||
|
Grid-Tied Operation
|
|
|
||
|
Output Voltage Range
|
195.5-253VAC
|
|
||
|
Nominal DC Voltage/Maximum DC Voltage
|
360VDC/500VDC
|
|
||
|
Start-up Voltage/Initial Feeding Voltage
|
90VDC/120VDC
|
|
||
|
MPPT DC Voltage Range
|
90-450VDC
|
|
||
|
Number of MPPT Trackers/Maximum Input Current
|
1/27A
|
|
||
|
Off-Grid Operation
|
|
|
||
|
Surge Power
|
8400W
|
12400W
|
||
|
AC Start-up Voltage/Auto Restart Voltage
|
120-140VAC / 180VAC
|
|
||
|
Acceptable Input Voltage Range
|
90-280VAC / 170-280VAC
|
|
||
|
Nominal Operating Frequency
|
50/60Hz
|
|
||
Features of Module ：
Pure Sine Wave Solar Inverter.
Self-consumption and feed-in to the grid.
Inverter running without battery.
One-key restoration to factory settings.
Built-in Lithium battery automatic activation.
Bulit-in 120A MPPT solar controller.
Max 6200W(for 3.6KW) & 6500W(for 6.2KW) solar charge.
High PV input voltage range(90-450VDC).
Built-in anti-dusk kit for harsh environment.
Smart battery charge design to optimize battery life.
Dual output.
WIFI available for IOS and Android.
Pure Sine Wave Solar Inverter.
Self-consumption and feed-in to the grid.
Inverter running without battery.
One-key restoration to factory settings.
Built-in Lithium battery automatic activation.
Bulit-in 120A MPPT solar controller.
Max 6200W(for 3.6KW) & 6500W(for 6.2KW) solar charge.
High PV input voltage range(90-450VDC).
Built-in anti-dusk kit for harsh environment.
Smart battery charge design to optimize battery life.
Dual output.
WIFI available for IOS and Android.
Advantage:
1. PV dual input, AC dual output;
2. Dual PV input: facilitate the connection of solar panel and reduce the use of combiner box
3. AC dual output: under normal conditions, the main circuit and secondary circuit outputs are used normally. When there is no PV and mains power input and the battery voltage is too low, the main circuit is disconnected and only the secondary circuit output is retained to save power.
1. PV dual input, AC dual output;
2. Dual PV input: facilitate the connection of solar panel and reduce the use of combiner box
3. AC dual output: under normal conditions, the main circuit and secondary circuit outputs are used normally. When there is no PV and mains power input and the battery voltage is too low, the main circuit is disconnected and only the secondary circuit output is retained to save power.
Inverter use notice：
1. The starting power of inductive load electrical appliances shall be at least three times of the rated power of the electrical appliances. If the starting power exceeds the inverter power, the inverter may be damaged. Please select a suitable model before purchasing.
2. Please connect the circuit correctly according to the instructions, and install switches for each circuit.
3. Starting sequence: first turn on the battery switch, start the inverter, and turn on the PV, mains and load switches.
4. Shutdown sequence: turn off the switches of load, PV and mains, turn off the inverter, and finally turn off the battery.
1. The starting power of inductive load electrical appliances shall be at least three times of the rated power of the electrical appliances. If the starting power exceeds the inverter power, the inverter may be damaged. Please select a suitable model before purchasing.
2. Please connect the circuit correctly according to the instructions, and install switches for each circuit.
3. Starting sequence: first turn on the battery switch, start the inverter, and turn on the PV, mains and load switches.
4. Shutdown sequence: turn off the switches of load, PV and mains, turn off the inverter, and finally turn off the battery.
Anern Factory
According to your needs, please feel free to contact us and know about other possible system architectures.
This inverter can power various electrical appliances in home or office environments, including light tubes, fans, refrigerators, air conditioners, and other motor-type appliances
This inverter can power various electrical appliances in home or office environments, including light tubes, fans, refrigerators, air conditioners, and other motor-type appliances
