Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Modo
-
Model Number:
-
MIS65-40-200A
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
As customer request
-
Cable Length:
-
/
-
Outlet Size:
-
As customer request
-
Power:
-
As customer request, Electric
-
Speed:
-
2900rpm
-
Pump Casing/Shaft Sleeve:
-
Cast iron
-
Shaft:
-
45#Steel
-
Shaft seal:
-
Packing seal
-
Motor Voltage/Frequency/Phase:
-
380V50hz/Three
Quick Details
-
Application:
-
Drinking water treatment, Irrigation and Agriculture, Raw Water Intake, Washing and Cleaning, Water Distribution
-
Pressure:
-
As customer request, High Pressure
-
Voltage:
-
380/400V
-
Warranty:
-
1 year
-
Brand Name:
-
Modo
-
Model Number:
-
MIS65-40-200A
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
As customer request
-
Cable Length:
-
/
-
Outlet Size:
-
As customer request
-
Power:
-
As customer request, Electric
-
Speed:
-
2900rpm
-
Pump Casing/Shaft Sleeve:
-
Cast iron
-
Shaft:
-
45#Steel
-
Shaft seal:
-
Packing seal
-
Motor Voltage/Frequency/Phase:
-
380V50hz/Three
20 hp 50hz electric standard horizontal end suction circulation centrifugal water pump machine
| Pump specification | Motor specification | ||
| Capacity | 20m3/hr | Power | 15kw |
| Head |
40m |
Speed | 2900rpm |
| Speed | 2900rpm | Volts | 380V |
| Inlet/Outlet | 65mm/40mm | Frequency | 50HZ |
| Efficiency | 55.8% | Protection grade | IP55 |
| NPSHr | 2m | Insulation class | F |
| Material List | |||
| Casing | Cast iron | Shaft | 45#Steel |
| Impeller | Cast iron | Shaft sleeve | Cast Iron |
| Shaft seal | Packing Seal | ||
|
·Usage: |
Clean Water |
|
·Type: |
MIS End Suction Water Pump |
|
·Capacity |
6.3-- 400 m3/hr |
|
·Head |
5- 125 m |
|
·Speed: |
1450/2900 rpm |
Model Meaning
IS 80-65-160 A
IS--- Single-stage end - suction pump
80—Inlet diameter (mm)
65—Outlet diameter (mm)
160—Nominal diameter of impeller (mm)
A—Impeller cutting mark
|
Model |
Speed |
Capacity Q |
Head |
Efficiency |
Power(N)(kW) |
NPSHr |
Weight |
||
|
n(r/min) |
m3/h |
L/S |
H (m) |
η (%) |
Shaft power |
Motor power |
r(m) |
w(Kg) |
|
|
IS50-32-125 ISR50-32-125
|
2900
|
7.5 |
2.08 |
22 |
47 |
0.96 |
1.5 |
2.0 |
32.5 |
|
12.5 |
3.47 |
20 |
60 |
1.13 |
2.0 |
||||
|
15 |
4.17 |
18.5 |
60 |
1.26 |
2.5 |
||||
|
1450 |
3.75 |
1.04 |
5.4 |
43 |
0.13 |
0.55 |
2.0 |
||
|
6.3 |
1.74 |
5 |
54 |
0.16 |
2.0 |
||||
|
7.5 |
2.08 |
4.6 |
55 |
0.17 |
2.5 |
||||
|
IS100-80-160 ISR100-80-160 |
2900 |
60 |
16.7 |
36 |
70 |
8.42 |
15 |
3.5 |
63 |
|
100 |
27.8 |
32 |
78 |
11.17 |
4.0 |
||||
|
120 |
33.3 |
28 |
75 |
12.2 |
5.0 |
||||
|
1450 |
30 |
8.33 |
9.2 |
67 |
1.12 |
2.2 |
2.0 |
||
|
50 |
13.9 |
8.0 |
75 |
1.45 |
2.5 |
||||
|
60 |
16.7 |
6.8 |
71 |
1.57 |
3.5 |
||||
|
IS125-100-315 ISR125-100-315 |
2900 |
120 |
33.3 |
132.5 |
60 |
72.1 |
110 |
4.0 |
178 |
|
200 |
55.6 |
125 |
75 |
90.8 |
4.5 |
||||
|
240 |
66.4 |
120 |
77 |
101.9 |
5.0 |
||||
|
1450 |
60 |
16.7 |
33.5 |
58 |
9.4 |
15 |
2.5 |
||
|
100 |
27.8 |
32 |
73 |
11.9 |
2.5 |
||||
|
120 |
33.3 |
30.5 |
74 |
13.5 |
3.0 |
||||
|
IS200-150-250 ISR200-150-250 |
1450 |
240 |
66.7 |
21.5 |
71 |
19.8 |
37 |
3.5 |
180 |
|
400 |
111.1 |
20 |
82 |
26.58 |
4.3 |
||||
|
460 |
127.8 |
17.5 |
80 |
27.4 |
5.0 |
||||
|
IS250-200-315 ISR250-200-315 |
1480 |
380 |
105.6 |
35.5 |
71 |
51.8 |
75 |
5.5 |
380 |
|
630 |
175 |
32 |
84.5 |
65.0 |
|||||
|
760 |
211.1 |
29 |
84 |
71.5 |
|||||
MIS series single stage end suction centrifugal water pump is designed according to the capability and size stipulated in the international Standard ISO2858, it is composed of pump body, pump cover, impeller, shaft, ring seal, sleeve and suspended bearing units etc.
Pump is for water or liquid similar to water, with high temperature mechanical seal. It also could be used to transfer hot water. The water pump is simple, reliable, small, light, and with good anti-cavitation performance, little power consumption and easy to maintain.
Pump Installation
• Have the pumps’s installation height, the pipeline length and diameter and the flowrate comply with the calculations and try best to reduce unnecessary loss.
• Use a bigger pipeline diameter for a distance transportation. The pump pipeline should have a stand of its own and do not let the pipeline weight upon the pump to avoid it from pressed damage.
• Mount the check value outside of the gate value on the drain-out pipeline if required to mount it.
