Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
shenghao
-
Model Number:
-
CM21111803
-
Product name:
-
truck body
-
Packing:
-
Neutral Packing
-
Color:
-
White
-
Certificate:
-
TS16949.ISO9001:2008
-
Quality:
-
100% Tested
-
Delivery:
-
Prompt Delivery
Quick Details
-
OE NO.:
-
none
-
Size:
-
4750*2100*2100
-
Material:
-
steel/aluminum/FRP/XPS
-
Place of Origin:
-
China
-
Brand Name:
-
shenghao
-
Model Number:
-
CM21111803
-
Product name:
-
truck body
-
Packing:
-
Neutral Packing
-
Color:
-
White
-
Certificate:
-
TS16949.ISO9001:2008
-
Quality:
-
100% Tested
-
Delivery:
-
Prompt Delivery
Product Description
Our product Structure:
1.Truck body is made of 25mm thickness Holypan, front and side wall for maximum weight saving.
2. 3mm steel floor structure or heavy-duty plywood floor structure
3. Aluminum profile all around and aluminum corner cap
4. Kick plate is possible around all walls
5. Rear door can be roll-up or double rear door with three hinges, seals and one camlock per door
6. LED light is possible according to your requirements.
Specification
TRUCK BODY CKD：
THE BOX PANEL CONSTRUCTION: xps sandwich panel, class B2 fire resistance, XPS foam thickness:40mm, density:30kg/m3,
Compressive strength:140-150kpa
outer skin/wall:PPGI(0.33mm thick) Inner wall/lining:PPGIll(0.33mm thick)
Checked steel floor:strong load bearing construction
Door rubble color:gray
Door& door trims: galvanized rear door frame, two door one right side door, Complete with locks,hardware,EPDM door gaskets,and
other accessories
Aluminum profiles.moldings: required c/w self-tap ss screws.rivets and other accessories
|
NO
|
box sizeLWH
|
Side door
|
FOB QINGDAO PORT
|
loading quantity
(20ft/40HC container) |
|
10*6*6ft
|
3040*1830*1830mm
|
with
|
|
15/36units
|
|
POP size
|
3300*1850*1850mm
|
with
|
|
15/36units
|
|
12*6*6ft
|
3650*1830*1830mm
|
with
|
|
12/26units
|
|
14*7*7ft
|
4280*2130*2130mm
|
with
|
|
10/24units
|
|
16*7*7ft
|
4880*2130*2130mm
|
with
|
|
10/22units
|
|
17*7*7ft
|
5150*2130*2130mm
|
with
|
|
9/20units
|
|
Name
|
Drawing number
|
quantity
|
|
Left plate
|
ZT-3300-8500101
|
1
|
|
Right plate
|
ZT-3300-8500102
|
1
|
|
Head plate
|
ZT-3300-8500103
|
1
|
|
Ceiling plate
|
ZT-3300-8500104
|
1
|
|
Aluminum profile used on the top of the side plate
|
ZT-3300-8500105
|
2
|
|
Aluminum profile used on the top of the head plate
|
ZT-3300-8500106
|
1
|
|
Aluminum profile used on the side of the head plate
|
ZT-3300-8500107
|
2
|
|
Aluminum profile used on the bottom of the side plate
|
ZT-3300-8500108
|
2
|
|
aluminum profile used on the bottom of the head plate
|
ZT-3300-8500109
|
1
|
|
Flat batten of side plate
|
ZT-3300-8500114
|
2
|
|
Flat batten of head plate
|
ZT-3300-8500115
|
1
|
|
Awning
|
ZT-3300-8500116
|
1
|
|
Angle iron of connecting the plate
|
ZT-3300-8500117
|
2
|
|
Rear door assembly
|
ZT-3300-8500200
|
1
|
|
Side door assembly
|
ZT-3300-8500300
|
1
|
|
Floor assembly
|
ZT-3300-8500400
|
1
|
|
Ceiling lamp
|
|
1
|
|
Switch
|
|
1
|
|
Lamp wire
|
|
15m
|
|
Circle angle
|
|
2
|
|
Height lamp
|
White, red
|
4
|
|
Self-plugging rivet
|
|
300
|
|
Neoprene
|
for the body
|
2
|
|
Polyurethane sealant
|
for the ceiling
|
4
|
