Quick Details
-
Warranty:
-
1Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Guangling
-
Model Number:
-
GF-800W
-
Speed:
-
1500/1800RPM, 1500/1800RPM
-
Weight:
-
20000
-
Model:
-
GF2-800W
-
Rated frequency:
-
50hz/60hz
-
Rated voltage:
-
400/230V
-
Rated power(kw):
-
800kva/640kw
-
Color:
-
optional
-
keywords:
-
800kva generator price
-
Packing:
-
Plywood Packing or Plastic Packing
-
Noise:
-
65-65DB
-
Phase:
-
Single
-
Certification:
-
CE,ISO
Quick Details
-
Rated Voltage:
-
400/230V
-
Rated Current:
-
1270A
-
Frequency:
-
50HZ/60HZ
-
Warranty:
-
1Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Guangling
-
Model Number:
-
GF-800W
-
Speed:
-
1500/1800RPM, 1500/1800RPM
-
Weight:
-
20000
-
Model:
-
GF2-800W
-
Rated frequency:
-
50hz/60hz
-
Rated voltage:
-
400/230V
-
Rated power(kw):
-
800kva/640kw
-
Color:
-
optional
-
keywords:
-
800kva generator price
-
Packing:
-
Plywood Packing or Plastic Packing
-
Noise:
-
65-65DB
-
Phase:
-
Single
-
Certification:
-
CE,ISO
Product Description
Power provide wide power range of diesel generator in various type. Even small farm or big mine project could find suitmodel perfectly match needed. Generator range cover 25kw-3650kw in Open type, Silent type, Movable type, Container type,Full-automatic switch system etc.
|
GENSET
|
Prime Power
|
Standby Power
|
Diesel
Engine model |
|
Alternator model
(copy stamford) |
|
control
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
KVA/KW
|
KVA/KW
|
SC33W1150D2
|
|
ON-850
(100%COPPER) |
|
Comap
IL3AMF9 |
|
|
|||||||||
|
DE-SH963
|
875/700
|
963/770
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Genset SIZE
|
|
|
|
|
4010*1630*2230MM(9.025CBM)
|
|
|
|
|
|||||||||
|
Weight
|
|
|
|
|
4650kgs
|
|
|
|
|
|||||||||
|
Fuel comsuptions 100% Loading
|
|
|
|
|
89L/H
|
|
|
|
|
|||||||||
|
Base Fuel tank
|
|
|
|
|
8-10hours fuel tank
|
|
|
|
|
|||||||||
|
Engine Data sheet
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Engine model
|
|
|
|
|
SC33W1150D2
|
|
|
|
|
|||||||||
|
Type
|
|
|
|
|
Water cooling,in line,four-stroke,wet liner and direct injection
|
|
|
|
|
|||||||||
|
Number of cylinders
|
|
|
|
|
8
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Bore/Stroke mm
|
|
|
|
|
126-155
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Displancement L
|
|
|
|
|
11.59
|
|
|
|
|
|||||||||
|
Compression ratio
|
|
|
|
|
0.709027778
|
|
|
|
|
|||||||||
|
Aspiration
|
|
|
|
|
turbo & inter cooler
|
|
|
|
|
|||||||||
|
Rated output kW
|
|
|
|
|
320
|
|
|
|
|
|||||||||
|
Rated speed r/min
|
|
|
|
|
1500
|
|
|
|
|
|||||||||
|
g/kW.h
Fuel consumption rate |
|
|
|
|
≤215
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
r/min
No load Speed |
|
|
|
|
≤1575
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
%
Steady speed adjusting rario at rated condition |
|
|
|
|
≤5
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Mpa
Oil pressure |
|
|
|
|
0.35-0.55
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
r/min
Idling speed |
|
|
|
|
≤650
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Mpa
Oil pressure at idle speed |
|
|
|
|
≥0.08
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
g/kW.h
Oil consumption rate |
|
|
|
|
1.63
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
L
Oil sump capacity |
|
|
|
|
30
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Starting method
|
|
|
|
|
Electric motor start
|
|
|
|
|
|||||||||
|
Lubricating method
|
|
|
|
|
Pressure lubrication
|
|
|
|
|
|||||||||
|
Crankshaft rotating direction
|
|
|
|
|
Counter clockwise(face to output end)
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Fring order
|
|
|
|
|
1-5-3-6-2-4
|
|
|
|
|
|||||||||
|
Engine size
|
|
|
|
|
1390×780×1410
|
|
|
|
|
|||||||||
|
Net mass kg
|
|
|
|
|
950
|
|
|
|
|
|||||||||
|
Alternator data sheet
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Brnad
|
|
|
|
|
Copy stamford
|
|
|
|
|
|||||||||
|
model
|
|
|
|
|
ON-850
(100%COPPER) |
|
|
|
|
|||||||||
|
Prime power
|
|
|
|
|
875KVA/700KW
|
|
|
|
|
|||||||||
|
Exciation mode
|
|
|
|
|
Brushless self-excitation
|
|
|
|
|
|||||||||
|
Power factor
|
|
|
|
|
0.8
|
|
|
|
|
|||||||||
|
Pressure regulating mode
|
|
|
|
|
AVR automatic pressure regulation
|
|
|
|
|
|||||||||
|
bearing
|
|
|
|
|
Long life and no need maintencances
|
|
|
|
|
|||||||||
|
Class of insulation
|
|
|
|
|
H grade
|
|
|
|
|
|||||||||
|
protection
|
|
|
|
|
IP23
|
|
|
|
|
|||||||||
Our Services
Guangling strictly adopt the international warranty.
Warranty: Guarantee for one year or 1000 running hours (accord to whichever reach first) from shipment date.
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
FAQ
Q1: What is your MOQ of this item?
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is
longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms
or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
