Quick Details
-
Ice storage capacity:
-
50kg, 80KG, 100KG, 200KG, 300Kg
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
136*920*120cm
-
Weight:
-
300 KG
-
Product name:
-
Sea Water Ice Flake Machine
-
Keyword:
-
Flake Ice Machine Flake Ice Machine
-
Name:
-
Flake Icemaking Machine
-
Cooling way:
-
Air Cooling Water Cooling
-
Material:
-
Stainless Steel 304
-
Control system:
-
Automatic Control System
-
Ice flake thickness:
-
1.5-2.5mm
-
Feature:
-
High Efficiency
-
Power supply:
-
3P/220V-440V/50Hz/60Hz(Optional)
Quick Details
-
Ice Shape:
-
Flake Ice
-
Voltage:
-
380v 50hz 3phrase
-
Power:
-
8750
-
Ice storage capacity:
-
50kg, 80KG, 100KG, 200KG, 300Kg
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
136*920*120cm
-
Weight:
-
300 KG
-
Product name:
-
Sea Water Ice Flake Machine
-
Keyword:
-
Flake Ice Machine Flake Ice Machine
-
Name:
-
Flake Icemaking Machine
-
Cooling way:
-
Air Cooling Water Cooling
-
Material:
-
Stainless Steel 304
-
Control system:
-
Automatic Control System
-
Ice flake thickness:
-
1.5-2.5mm
-
Feature:
-
High Efficiency
-
Power supply:
-
3P/220V-440V/50Hz/60Hz(Optional)
High Productivity Energy saving stainless steel 1t 2t 3t 5t 8T 10T 15T 20T 30 Ton flake ice machine For Fish Seafood Market
Ice Flake Machine Introduction:
The ice flake machine is a leader in fast and large-scale refrigeration projects, and is widely used in supermarket food
preservation, fishery protection, food processing, concrete cooling, etc.
preservation, fishery protection, food processing, concrete cooling, etc.
Flake Ice Machine 1 2 3T 5 10 Ton 15 20 30 40 Tons Commercial Industrial Flake Ice Making Machine Factory Supply Ice Maker For Food & Meat processing & Fishing & Seafood Ice Maker
Title goes here.
1) Fishing -Sea water flake ice machine can make ice directly from the sea water, ice can be used in fast cooling of fish and other sea products.
2) Sea food process -keeps the sea food fresh.
3) Bakery -prevent the flour from self raising by adding flake ice.
4) Food processing - cool the meat and water air, also supply moisture for the products at the meantime.
5) Vegetables distribution and fresh-keeping.
6) Flake ice is the most ideal temperature-reducing carrier.
7) Concrete Cooling -Flake ice is widely used in the large projects.
|
Model Number
|
BMF-03T, BMF-05T, BMF-1T, BMF-2T, BMF-3T, BMF-4T, BMF-5T, BMF-6T, BMF-8T, BMF-10T, BMF-12T, BMF-15T, BMF-20T, BMF-30T, BMF-40T
|
|
Capacity
|
300kg/day, 500kg/day, 1 ton/day, 2 tons/day, 3 tons/day, 4 tons/day 5 tons/day, 6 tons/day, 8 tons/day, 10 tons/day, 12 tons/day,
15 tons/day, 40 tons/day, 50 tons/day, 100 tons/day |
|
Applicable Industries
|
Food & Beverage Factory, Restaurant, Food Shop, Energy & Mining, Food & Beverage Shops
|
|
After Warranty Service
|
Video technical support, Online support
|
|
Ice Shape
|
Snow Flake Ice
|
|
ower supply
|
3P/1P + 380V/220V/110V + 50hz/60hz
|
|
Power
|
18.49~53.42kw
|
|
Dimension(L*W*H)
|
1850*1700*1555~3900*2150*1920mm
|
|
Weight
|
672KG ~ 2250KG
|
|
Core Components
|
Pressure vessel, Motor, Bearing, Gear, Engine, PLC
|
|
After-sales Service Provided
|
Engineers available to service machinery overseas
|
|
Refrigerant
|
R404A
|
|
compressor
|
Bitzer from Germany, Refcomp from Italy, Danfoss from Danmark
|
|
cooling type
|
water cooling
|
|
ice thickness
|
1.8~2.5mm
|
|
Warranty
|
12 months
|
Special design of flake ice machine:
1. Refrigerating unit -- Compressor are imported from America, Germany, Japan.
2. PLC programmable control system -- The whole system is controlled automatically well without hand operation.
3. Evaporator-- made of SUS304/316 material and adopts automatic fluorine welding technology.
4. Ice blade--Spiral ice blade, small resistance, low loss, no noise and making ice in uniform.
◆ Product Parameter ◆
|
Model
|
Output
|
Refrigerate Capacity
|
Total Power
|
Rated Current
|
Compressor Power
|
Refrigerant
|
Cooling Way
|
Unit Size
L*W*H (mm) |
|
BMF03
|
0.3T
|
2.1KW
|
1.9KW
|
4.3A
|
1.5KW
|
R22/R404A
|
Water
|
950*800* *680
|
|
BMF05
|
0.5T
|
3.5KW
|
2.45KW
|
5.6A
|
2.1KW
|
R22/R404A
|
Water
|
950*800* 810
|
|
BMF08
|
0.8T
|
5KW
|
3.5KW
|
7A
|
2.9KW
|
R22/R404A
|
Water
|
1320*970*850
|
|
BMF10
|
1T
|
6.35KW
|
4.33KW
|
8.66A
|
3.6KW
|
R22/R404A
|
Air/ Water
|
1320*970*900
|
|
BMF20
|
2T
|
12.9KW
|
8.66KW
|
17.3A
|
5.88KW
|
R22/R404A
|
Air/ Water
|
1500*1100*1050
|
|
BMF30
|
3T
|
21.5KW
|
13KW
|
26A
|
9.7KW
|
R22/R404A
|
Air/ Water
|
1745*1360*1250
|
Details Images
Main Features:
1. The ice flake machine adopts modular design, which is easy to assemble and maintain; the parts are processed by CNC machine tools with high precision and avoid welding defects.
2.
The ice flake machine
Using high-precision bearings imported from Japan, the mechanism runs smoothly and has long service life.
3. The ice flake machine, One key to start the ice storage mode. After the ice cubes fall into the ice storage, the ice rake automatically runs according to the signal instructions provided by the sensor, and automatically stops when the ice storage reaches the maximum.
4. The ice flake machine, One-button start of the ice release mode, the ice blocking door opens automatically, the ice rake runs automatically according to the signal instruction provided by the sensor, and automatically stops after the ice output is completed, and the ice blocking door returns to its position.
5. Smart electric control screen, simple and easy to use.
6.Monitoring equipment is installed in the cold storage, which can check the working conditions of the equipment in real
time,which is convenient for maintenance and management and safe production.
3. The ice flake machine, One key to start the ice storage mode. After the ice cubes fall into the ice storage, the ice rake automatically runs according to the signal instructions provided by the sensor, and automatically stops when the ice storage reaches the maximum.
4. The ice flake machine, One-button start of the ice release mode, the ice blocking door opens automatically, the ice rake runs automatically according to the signal instruction provided by the sensor, and automatically stops after the ice output is completed, and the ice blocking door returns to its position.
5. Smart electric control screen, simple and easy to use.
6.Monitoring equipment is installed in the cold storage, which can check the working conditions of the equipment in real
time,which is convenient for maintenance and management and safe production.
