Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ruijie
-
Voltage:
-
380V 50HZ
-
Dimension(L*W*H):
-
6000*950*2600mm
-
Power (kW):
-
120
-
Weight:
-
5000 KG
-
Raw material:
-
PVC Resins+CaCo3
-
Usage:
-
Make Sheet
-
Capacity:
-
200-250kg/h
-
Keywords:
-
Sheet Line
-
Inverter:
-
ABB Inverter
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
30:1
-
Screw Speed (rpm):
-
28 rpm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ruijie
-
Voltage:
-
380V 50HZ
-
Dimension(L*W*H):
-
6000*950*2600mm
-
Power (kW):
-
120
-
Weight:
-
5000 KG
-
Raw material:
-
PVC Resins+CaCo3
-
Usage:
-
Make Sheet
-
Capacity:
-
200-250kg/h
-
Keywords:
-
Sheet Line
-
Inverter:
-
ABB Inverter
75 Co-rotating Parallel twin screw extruder
Screw diameter： 75mm
Draw ratio：44:1
Motor：60KW
Cooling method：
Circulating water pump: motor power 0.55kw
Solenoid valve: Adopt Danfoss or CKD brand; the cooling water inlet and return pipes are made of stainless steel, and the water
inlet regulating valve of each cylinder is stainless steel.
Solenoid valve: Adopt Danfoss or CKD brand; the cooling water inlet and return pipes are made of stainless steel, and the water
inlet regulating valve of each cylinder is stainless steel.
Meltmetering pump and screen changer
Hydraulic drive：
Manual control, hydraulic net change
Structure form：
Double column type simplex 120
PET Sheet Mould
Structure: Clothes bracket
Material:
High quality mould steel
Mould width: 1350mm
Three roller calender machine
Mechanical worm and gear adjustment , All stop switch, Synchronous control system
Cooling bracket
Bracket length：3 meters
Specification: Ф200×1600mm
Controller； Servo control
Transmission:
Servo motor
Type:
Double station independent winder
Qingdao Ruijie Plastic Machinery Co., Ltd. is located in Jiaozhou Town ,Qingdao City ,Shandong Province . It takes about 30 minutes from the company to Qingdao airport . With multiple high-speed roads go across Jiaozhou Town ,the traffic is very convenient.
Company Certificates:Ruijie Plastic Machinery Company has passed ISO9001 Quality Management System Certificate, ISO4001 Environmental Management System Certificate , CE Certificate and other certificates.
Company Philosophy:Ruijie Plastic Machinery Company takes the technology as the most important and makes the better machine. We owns the business philosophy of directing by market ,living on the machine quality, developing on the innovation. We try to create value for clients and grow together with clients.
