Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
IB-AT07-75A
-
Product name:
-
75A Bipolar connector
-
Rated Current:
-
75A
-
Rated Voltage:
-
600V
-
Internal shrapnel:
-
65Mn
-
Connector Speciflcation (AWG USA):
-
12AWG
-
Terminal Material:
-
Cu/Ep & Ag
-
FlammaBility:
-
UL94V-0
-
Shell Material:
-
PC
-
Working Temperature:
-
-20℃~105℃
-
product type:
-
anderson connector
Quick Details
-
Type:
-
Anderson
-
Application:
-
Power
-
Gender:
-
Female/Male
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
IB-AT07-75A
-
Product name:
-
75A Bipolar connector
-
Rated Current:
-
75A
-
Rated Voltage:
-
600V
-
Internal shrapnel:
-
65Mn
-
Connector Speciflcation (AWG USA):
-
12AWG
-
Terminal Material:
-
Cu/Ep & Ag
-
FlammaBility:
-
UL94V-0
-
Shell Material:
-
PC
-
Working Temperature:
-
-20℃~105℃
-
product type:
-
anderson connector
Products Description
Product overview
There are gray and red plastic shells respectively, to avoid mis-insertion of plastic shells with two different voltage coding colors
The design of the plug does not distinguish between male and female, which simplifies assembly requirements and reduces component inventory
Application:
Various types of electric vehicles: electric forklifts, electric buses, golf carts, tourist vehicles, tractors; communication power supplies: batteries, UPS AC and DC regulated power supplies, inverters, high frequency
Module power supply extremely high frequency charging system motor machinery, electric wheelchair, electric washing machine, lawn mower, vacuum cleaner, medical equipment, material handling equipment. Power distribution equipment for rechargeable battery applications;
A series of high-current connectors of various brands have been widely used in national large-scale electric machinery research and development projects and transportation and railway products.
Product Paramenters
|
Model Specification
|
|
|
|
Product name
|
75A Bipolar connector
|
|
|
Rated current
|
75A
|
|
|
Rated Voltage
|
600V
|
|
|
Terminal material
|
Cu/Ep & Ag
|
|
|
Plastic case material
|
PC
|
|
|
Fire-proof level
|
UL94V-0
|
|
|
Internal shrapnel
|
65Mn
|
|
|
ambient temperature
|
-20℃~105℃
|
|
|
Connection specification
|
12AWG
|
|
