Quick Details
-
Weight:
-
200 KG
-
Dimension(L*W*H):
-
1440*710*800
-
Product Name:
-
Farm Tractor 5 Disc Plough Mf Plough for Sale
-
Usage:
-
Ploughing Soil
-
Color:
-
Optional
-
Application:
-
Agri Cultivator
-
Linkage:
-
Standard Three-point Mounted
-
Matched power:
-
70-90hp
-
Displacement:
-
52cc
Quick Details
-
Use:
-
Farm
-
Place of Origin:
-
shandong
-
Brand Name:
-
Tavol
-
Weight:
-
200 KG
-
Dimension(L*W*H):
-
1440*710*800
-
Product Name:
-
Farm Tractor 5 Disc Plough Mf Plough for Sale
-
Usage:
-
Ploughing Soil
-
Color:
-
Optional
-
Application:
-
Agri Cultivator
-
Linkage:
-
Standard Three-point Mounted
-
Matched power:
-
70-90hp
-
Displacement:
-
52cc
Tractor Mounted 3 Discs Disc Plough for South Africa
Product Description
1LYQ9 ( T) disc plough with horizontal pendulum structure, is applicable for the dry land, particularly, suit to high-yielding green manure land and rice and wheat land. It has strong ability to rake, small farming resistance and is easy to adjust,etc. It meets the requirement of agricultural production.
| Tavol One-Way Light-Duty Disc Plough Main Parameters | |||||||
| Type | Working width(mm) | Wroking depth(mm) | No. of disc(pc) | Dia of disc(mm) | Weight(kg) | Linkage | Matched power(hp) |
| 1LYQ-315 | 600 | 180 | 3 | 460 | 170 | 3-point mounted | 18-25 |
| 1LYQ-220 | 400 | 200 | 2 | 510 | 160 | 25-30 | |
| 1LYQ-320 | 600 | 200 | 3 | 510 | 190 | 25-40 | |
| 1LYQ-420 | 800 | 200 | 4 | 510 | 250 | 50 | |
| 1LYQ-325 | 750 | 250-300 | 3 | 660 | 420 | 65-70 | |
| 1LYQ-425 | 1000 | 250-300 | 4 | 660 | 480 | 80 | |
| 1LYQ-525 | 1250 | 250-300 | 5 | 660 | 580 | 100 | |
| 1LYQ-625 | 1500 | 250-300 | 5 | 660 | 700 | 120 | |
| 1LYQ-230 | 600 | 300 | 2 | 710 | 400 | 35-55 | |
| 1LYQ-330 | 900 | 300 | 3 | 710 | 530 | 55-70 | |
| 1LYQ-430 | 1200 | 300 | 4 | 710 | 580 | 70-90 | |
