Quick Details
-
Size:
-
230x105x44mm
-
Video/Audio Input:
-
8xHDMI
-
Video/Audio Codec:
-
H.264/AAC,MP3
-
Input Resolution:
-
Up to 1080p60
-
Chip Lantency:
-
<100ms
-
Protocol:
-
SRT/RTSP/RTMP/UDP
-
Temperature:
-
0-45(work),-20-80(storage)
-
Power:
-
12V DC 2A
-
Consumption:
-
10W
-
Ethernet Port:
-
1000M
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unisheen
-
Model Number:
-
BM4008H
-
Size:
-
230x105x44mm
-
Video/Audio Input:
-
8xHDMI
-
Video/Audio Codec:
-
H.264/AAC,MP3
-
Input Resolution:
-
Up to 1080p60
-
Chip Lantency:
-
<100ms
-
Protocol:
-
SRT/RTSP/RTMP/UDP
-
Temperature:
-
0-45(work),-20-80(storage)
-
Power:
-
12V DC 2A
-
Consumption:
-
10W
-
Ethernet Port:
-
1000M
Product Description
| Video | |
| Input | 8x HDMI( 1.4) HDCP |
| Resolution | 1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p 720x576i/720x480i |
| Encoding | H.264/AVC Baseline/Main/High Profile Level 4.2 |
| Encoding Output FPS | 1080P60(only input 1080P60) |
| Data Rate | 0.16Mbps~32Mbps |
| Rate Control | CBR/VBR |
| GOP Structure | IBBP |
| Advanced Pretreatment | De-interlacing, Image Enhancement,Noise Reduction, Sharpening |
| Latency Time | 200ms |
| Audio | |
| Input | 8xHDMI |
| Encoding | AAC/AAC+/MP3 |
| Sampling rate | 44100/48000 Hz |
| Bit-rate | 32K/48K/64K/96K/128K/160K/192K/384K |
| Sampling precision | 24 bit |
| System | |
| Ethernet | 1000 Base-T Ethernet interface |
| Protocol | HTTP RTSP RTMP HLS FLV UDP unicast/multicast |
| control interface | WEB Manager |
| General | |
| Rack Dimension (W×L×H) | 230x150x44mm |
| Packing Box(WxLxH) | 300x220x60mm |
| Net Weight/Gross Weight | 0.5kg/1.2kg |
| Temperature | 0-45(work),-20-80(storage) |
| Power | 12V DC 2A |
| Consumption | 15w |
