Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yitong
-
Dimension(L*W*H):
-
Please refer to exact model
-
Weight (KG):
-
35 KG
-
Product name:
-
Explosion Proof Air Curtain
-
Explosion proof Mark:
-
Ex d e IIC T4 Gb
-
Impeller Diameter:
-
125
-
Air SupplyType:
-
with Electric Heater
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Manufacturer:
-
Nanyang Yitong Explosion proof Electric Co.,Ltd.
-
After warranty Service:
-
Video technical support
-
Local service Location:
-
South Korea, UAE, Russia, Egypt
-
Certification:
-
CNEX,CCS(if necessary),ISO,OHSAS
Quick Details
-
Type:
-
Air Curtain
-
Mounting:
-
Split, Door/Wall/Window Mount
-
Airflow:
-
as shown
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yitong
-
Dimension(L*W*H):
-
Please refer to exact model
-
Weight (KG):
-
35 KG
-
Product name:
-
Explosion Proof Air Curtain
-
Explosion proof Mark:
-
Ex d e IIC T4 Gb
-
Impeller Diameter:
-
125
-
Air SupplyType:
-
with Electric Heater
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Manufacturer:
-
Nanyang Yitong Explosion proof Electric Co.,Ltd.
-
After warranty Service:
-
Video technical support
-
Local service Location:
-
South Korea, UAE, Russia, Egypt
-
Certification:
-
CNEX,CCS(if necessary),ISO,OHSAS
900 1200 1500mm Explosion Proof Air Curtain with Electric Heater For Door Ventilation
Product Features
1, Arc elegant shape design, light weight and thin; The casing uses aluminum alloy and high precision ABS and own a good anti-corrosion performance.
2, Can realize cold insulation, heat insulation, dust, insect control, energy saving, environmental protection and so on.
3, Ultra-thin filter, environmental protection materials; Detachable air inlet/outlet is easier to clean and do maintenance.
4, It adopts high quality explosion-proof motor, which is with high efficiency, long life, reliable performance.
5, Various types optional: it can be divided into natural wind from the aspect of air treatment mode, PTC electric heating, hot water heating and steam heating; According to the mode of air supply into tubular and centrifugal.
- 6.The explosion-proof performance is stable and reliable. It adopts the latest national explosion-proof standard, and the whole machine has obtained the explosion-proof certificate issued by the China National Quality Supervision and Inspection Center for explosion-proof electrical products.
Technical Parameters 1
-Applicable to door height 2.6m or below
|
|
BFM-9
|
BFM-12
|
BFM-15
|
||
|
Supply Air Type
|
Warm Air（Wind）
|
|
|
||
|
Control Mode
|
Optional:Manual/ Remote Control
|
|
|
||
|
Suitable Door Height Range
|
≤2600mm
|
|
|
||
|
Air Curtain Length
|
900
|
1200
|
1500
|
||
|
Impeller Diameter
|
150mm
|
|
|
||
|
Power Supply
|
380V50HZ
|
|
|
||
|
Rated Power（kw）
|
0.18
|
0.18
|
0.25
|
||
|
PTC Electric Heater Power（kw）
|
8
|
12
|
16
|
||
|
Air Outlet Wind Speed(m/s)
|
6~7
|
|
|
||
|
Air Volume(m3/h)
|
1500~1860
|
2350~3000
|
2850~3800
|
||
|
Noise dB(A）
|
56~58
|
58~60
|
60~62
|
||
|
Weight（kg）
|
26
|
31
|
36
|
||
|
Dimension（W*D*H）
|
900*240*270
|
1200*240*270
|
1500*240*270
|
||
|
Explosion-proof Mark
|
Ex d e IIC T4 Gb
|
|
|
||
|
|
BFM-9
|
BFM-12
|
BFM-15
|
||
|
Supply Air Type
|
Warm Air
|
|
|
||
|
Applicable Door Height(mm)
|
≤3500
|
|
|
||
|
Air Curtain Length(mm)
|
900
|
1200
|
1500
|
||
|
Impeller Diameter(mm)
|
200
|
|
|
||
|
Power Supply
|
380V/50HZ others please contact
|
|
|
||
|
Rated Power(kw)
|
0.37
|
0.55
|
0.55
|
||
|
PTC Electric Heater Power（kw）
|
8
|
12
|
16
|
||
|
Air Outlet Air Speed(m/s)
|
10
|
|
|
||
|
Air Volume(m/s)
|
2600
|
3450
|
4300
|
||
|
Noise dB(A)
|
58~60
|
60
|
62~64
|
||
|
Weight(kg)
|
37
|
45
|
52
|
||
|
Dimension(W*D*H)mm
|
900*320*315
|
1200*320*315
|
1500*320*315
|
||
|
Explosion-proof Mark
|
Ex d e IIC T4 Gb
|
|
|
||
