Quick Details
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
L(260-500)mm*W(200-450)mm*H(150-400)mm
-
Weight:
-
600 KG
-
Body weight:
-
62kg
-
payload:
-
20kg
-
Working radius:
-
1600mm
-
Maximum arm span:
-
1600mm
-
Rated voltage:
-
220v
-
Maximum working speed:
-
1.2m/s
-
Joint range of motion:
-
360°
-
Maximum joint velocity:
-
148°/s
-
Control box:
-
16
-
Repeated positioning accuracy:
-
±0.04mm
Quick Details
-
Application:
-
Food, Palletizer machine
-
Packaging Material:
-
Wood, Palletizer machine
-
Voltage:
-
220V 50HZ or 60HZ
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
L(260-500)mm*W(200-450)mm*H(150-400)mm
-
Weight:
-
600 KG
-
Body weight:
-
62kg
-
payload:
-
20kg
-
Working radius:
-
1600mm
-
Maximum arm span:
-
1600mm
-
Rated voltage:
-
220v
-
Maximum working speed:
-
1.2m/s
-
Joint range of motion:
-
360°
-
Maximum joint velocity:
-
148°/s
-
Control box:
-
16
-
Repeated positioning accuracy:
-
±0.04mm
WB-MDJ16 Robot Palletizer Packaging Machine
Features
Customized box and customized pallet scale
Customized box position and sequence
Stacking simulation and collision detection
User Can Extend Functions Flexibility
Replace to user-defined end of arm tooling
Add more visual functions such as bar code recognition
Apply an additional sensor for induction detection before placing the carton
Add partition application relevant action flow
Main Functions
Lifting correction
Set various machine / operation parameters in application.
Safety and Stability
Can work directly side by side with man without protective isolation, high reliability and safety to human being;
Support L10 collision detection as well as sensor safety detection;
16pcs safety I/O connections are provided, safety function will not be lost in case of fault;
The end does not fall when it is powered off, ensure a safe and stable working.
Product Paramenters
|
Model
|
WB-MDJ16 Robot Palletizer Machine
|
|
|
Speed
|
6-8 caes per min
|
|
|
Machine dimension
|
3950*1724mm
|
|
|
Max Load
|
20kg
|
|
|
Pallet Working Radius
|
1600mm
|
|
|
Robot Arm Span
|
1600mm (Customizable wider range)
|
|
|
Pallet Size
|
800*1200mm/1000*1200mm/1200*1200mm
|
|
|
Case size range
|
L（260-500）mm*W（200-450）mm*H（150-400）mm
|
|
|
Power Supply
|
200-240V 50/60Hz
|
|
|
Palletizing Height
|
1650mm(including pallet) can be customized to 3000mm
|
|
|
Max. Working Speed
|
1.2M/S
|
|
|
Range of Motion(ROM)
|
J1 : ±360°
|
|
|
|
J2 : ±125°
|
|
|
|
J3 : ±160°
|
|
|
|
J4 : ±180°
|
|
|
|
J5 : ±360°
|
|
|
|
J6 : ±360°
|
|
|
Max.Speed of Motion
|
J1/J2/J3: 148°/s
|
|
|
|
J4/J5/J6: 186°/s
|
|
|
Communication Type
|
EtherCAT
|
|
|
IP Grade
|
IP54
|
|
|
Temperature Range
|
0-55ºC
|
|
|
Power Consumption
|
2950w
|
|
|
Material
|
Aluminum alloy, Carbon fiber
|
|
Details Images
Cooperative Robot
Workstation deployment new task setup is simple, fast and efficient
Spongy Sucker
Soft does not hurt the item, can be customized to replace different grippers
Lifting Column
Can be adjusted according to the height needs, simple operation
Pallet and base with the gaps for forklift truck
Large size pallet, safe and stable
Palletizer work station
Conveyor belt -- palletizer -- fence -- grating induction
Recommend Products
Automatic unpacking machine -- automatic sealing machine -- palletizer
Work for small or big carton boxes, save labor
We also produce :
fully automatic bag packing machines and bottle filling machines
