- Product Details
- {{item.text}}
Quick Details
-
Rated Voltage:
-
120V/220V/230V/240V
-
Rated Current:
-
2A to 55A
-
Speed:
-
3000/3600RPM
-
Frequency:
-
50HZ/60HZ
-
Certificate of of gasoline generator:
-
ISO/CE
-
Color of of gasoline generator:
-
Customer Required
-
Function:
-
Small Generator Provide Electric Power
-
Type of of gasoline generator:
-
Open and silent Frame
-
Starting system:
-
Recoil Start/Electric Start
-
Engine type:
-
Air-cooled 4-stroke
-
Output Power:
-
1.5kw-12kw
-
Phase:
-
1-phase
-
Packing:
-
Carton Packing 1set/1carton
-
Warranty of gasoline generator:
-
1 Year or 1800 working hours
-
Certification:
-
ISO/CE
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Gencircle
-
Model Number:
-
WP3800
-
Rated Voltage:
-
120V/220V/230V/240V
-
Rated Current:
-
2A to 55A
-
Speed:
-
3000/3600RPM
-
Frequency:
-
50HZ/60HZ
-
Certificate of of gasoline generator:
-
ISO/CE
-
Color of of gasoline generator:
-
Customer Required
-
Function:
-
Small Generator Provide Electric Power
-
Type of of gasoline generator:
-
Open and silent Frame
-
Starting system:
-
Recoil Start/Electric Start
-
Engine type:
-
Air-cooled 4-stroke
-
Output Power:
-
1.5kw-12kw
-
Phase:
-
1-phase
-
Packing:
-
Carton Packing 1set/1carton
-
Warranty of gasoline generator:
-
1 Year or 1800 working hours
-
Certification:
-
ISO/CE
Product Details
|
Model
|
WP2500
|
WP3500
|
WP3800
|
WP4500
|
|||
|
AC Frequency (Hz)
|
50Hz / 60Hz
|
50Hz / 60Hz
|
50Hz / 60Hz
|
50Hz / 60Hz
|
|||
|
AC Output voltage(V)
|
120;220;230;240;
|
120;220;230;240;
|
120;220;230;240;
|
120;220;230;240;
|
|||
|
Rated Power
|
1800W
|
2000W
|
2500W
|
2800W
|
|||
|
Max. Power
|
2000W
|
2200W
|
2800W
|
3100W
|
|||
|
Power Factor
|
1
|
1
|
1
|
1
|
|||
|
DC Output
|
12V/8.3A
|
12V/8.3A
|
12V/8.3A
|
12V/8.3A
|
|||
|
Engine
|
GE210
|
GE210
|
GE210
|
GE210
|
|||
|
Type
|
4-stroke OHV; Air-cooled; Gasoline Engine
|
|
|
|
|||
|
Displacement(cc)
|
212
|
212
|
212
|
212
|
|||
|
Starting System
|
Recoil or Electric
|
Recoil or Electric
|
Recoil or Electric
|
Recoil or Electric
|
|||
|
Lubrication oil
|
SAE 10W/30
|
SAE 10W/30
|
SAE 10W/30
|
SAE 10W/30
|
|||
|
Oil capacity (L)
|
0.6L
|
0.6L
|
0.6L
|
0.6L
|
|||
|
Compression ratio
|
8.5:1
|
8.5:1
|
8.5:1
|
8.5:1
|
|||
|
Bore×Stroke
|
70mm×54mm
|
70mm×54mm
|
70mm×54mm
|
70mm×54mm
|
|||
|
Max.Output(hp/rpm)
|
7.0/3600
|
7.0/3600
|
7.0/3600
|
7.0/3600
|
|||
|
Fuel Consumption (g/hp.h)
|
≤360
|
≤360
|
≤360
|
≤360
|
|||
|
Ignition System
|
Non-contact transistorized ignition (T.C.I)
|
|
|
|
|||
|
Spark Plug
|
F6TC
|
F6TC
|
F6TC
|
F6TC
|
|||
|
Fuel Tank Capacity(l)
|
15
|
15
|
15
|
15
|
|||
|
Continuous Work(h)
|
12
|
11
|
11
|
11
|
|||
|
Noise Level LwA dB(A)
|
67
|
67
|
67
|
67
|
|||
|
Dimension (LxWxH) mm
|
610X440X440
|
610X440X440
|
610X440X440
|
610X440X440
|
|||
|
Gross Weight(kg)
|
38
|
40
|
42
|
43
|
|||
|
20ft Container Qty
|
245
|
245
|
245
|
245
|
|||
|
40ft HQ Container Qty
|
590
|
590
|
590
|
590
|
|||
|
Model
|
WP5500
|
WP6500
|
WP7500
|
WP8500
|
|||
|
AC Frequency (Hz)
|
50Hz / 60Hz
|
50Hz / 60Hz
|
50Hz / 60Hz
|
50Hz / 60Hz
|
|||
|
AC Output voltage(V)
|
120;220;230;240;
|
120;220;230;240;
|
120;220;230;240;
|
120;220;230;240;
|
|||
|
Rated Power
|
4500W
|
5000W
|
6000W
|
7000W
|
|||
|
Max. Power
|
5000W
|
5500W
|
7000W
|
8000W
|
|||
|
Power Factor
|
1
|
1
|
1
|
1
|
|||
|
DC Output
|
12V/8.3A
|
12V/8.3A
|
12V/8.3A
|
12V/8.3A
|
|||
|
Engine
|
GE420
|
GE420
|
GE460
|
GE460
|
|||
|
Type
|
4-stroke OHV; Air-cooled; Gasoline Engine
|
|
|
|
|||
|
Displacement(cc)
|
420
|
420
|
439
|
439
|
|||
|
Starting System
|
Recoil or Electric
|
Recoil or Electric
|
Recoil or Electric
|
Recoil or Electric
|
|||
|
Lubrication oil
|
SAE 10W/30
|
SAE 10W/30
|
SAE 10W/30
|
SAE 10W/30
|
|||
|
Oil capacity (L)
|
1.1
|
1.1
|
1.1
|
1.1
|
|||
|
Compression ratio
|
8.0:1
|
8.0:1
|
8.0:1
|
8.0:1
|
|||
|
Bore×Stroke
|
90mm×66mm
|
90mm×66mm
|
92mm×66mm
|
92mm×66mm
|
|||
|
Max.Output(hp/rpm)
|
15/3600
|
15/3600
|
16/3600
|
16/3600
|
|||
|
Fuel Consumption (g/hp.h)
|
≤390
|
≤390
|
≤390
|
≤390
|
|||
|
Ignition System
|
Non-contact transistorized ignition (T.C.I)
|
|
|
|
|||
|
Spark Plug
|
F6TC
|
F6TC
|
F6TC
|
F6TC
|
|||
|
Fuel Tank Capacity(l)
|
25
|
25
|
25
|
25
|
|||
|
Continuous Work(h)
|
10
|
10
|
10
|
6
|
|||
|
Noise Level LwA dB(A)
|
74
|
74
|
74
|
74
|
|||
|
Dimension (LxWxH) mm
|
697X525X562
|
697X525X562
|
713X541X569
|
713X541X569
|
|||
|
Gross Weight(kg)
|
79
|
81
|
83
|
86
|
|||
|
20ft Container Qty
|
135
|
135
|
135
|
135
|
|||
|
40ft HQ Container Qty
|
292
|
292
|
280
|
280
|
|||
* Optional electric start with battery, wheels kit
Product Details Show
Genset Certification
GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34
Warranty
one year or 1000 hours whichever reach first from exfactory date.
1. During the guarantee period-
we will provide the free easydamageable spare parts of alternator caused by our quality of production or raw material.
2. After expiration-
our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.
