- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
zhaowei
-
Model Number:
-
micro gear motor
-
Torque:
-
custom
-
Motor Type:
-
stepper motor
-
Range Voltage:
-
3.0V
-
Gearbox & Motor Dia:
-
3.4mm & 3.4mm
-
No Load Current:
-
220mA
-
Load Current:
-
220mA
-
Rated Torque:
-
10gf.cm
-
Rated Torque of Gear Box:
-
50 gf.cm
-
Instant Torque of Gear Box:
-
150 gf.cm
-
Gear Box Length:
-
9.0mm
-
Certification:
-
iso,ce
Quick Details
-
Speed(RPM):
-
5rpm-1500rpm
-
Continuous Current(A):
-
custom
-
Efficiency:
-
IE 2
-
Place of Origin:
-
China
-
Brand Name:
-
zhaowei
-
Model Number:
-
micro gear motor
-
Torque:
-
custom
-
Motor Type:
-
stepper motor
-
Range Voltage:
-
3.0V
-
Gearbox & Motor Dia:
-
3.4mm & 3.4mm
-
No Load Current:
-
220mA
-
Load Current:
-
220mA
-
Rated Torque:
-
10gf.cm
-
Rated Torque of Gear Box:
-
50 gf.cm
-
Instant Torque of Gear Box:
-
150 gf.cm
-
Gear Box Length:
-
9.0mm
-
Certification:
-
iso,ce
| Motor Specifications:4mm motor | |
| motors(optional) | stepper motor |
| voltage(optional) | 3v |
| input speed | <=10000rpm |
| current | 50mA max |
| Performance Data:4mm planetary gear stepper motor | ||||||
| Model |
Speed at 2000pps
|
Max Rated Torque | Max Instant Torque | Reduction Ratio | gearbox Length | Overall Length |
| rpm | gf.cm | gf.cm | mm | mm | ||
| MD004004-6 | 1000.0 | 140 | 400 | 5 | 6.18 | 11.78 |
| MD004004-36 | 166.6 | 140 | 400 | 25 | 7.67 | 13.27 |
| MD004004-216 | 27.7 | 140 | 400 | 125 | 9.17 | 14.77 |
| MD004004-1296 | 4.6 | 140 | 400 | 625 | 10.72 | 16.32 |
| * The above specifications are subject to change without prior notice. They are for reference only and can be customized as required. | ||||||
