Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
UV-972-2133
-
Visible Sensor:
-
1/2.8" Progressive Scan CMOS
-
Certification:
-
ce
-
Support:
-
Onvif Protocol
-
Technology:
-
NetWork IP Camera
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
128 GB
-
Magnification:
-
33x
-
Focal Length:
-
5~180mm
-
Power:
-
DC 12V
Quick Details
-
Special Features:
-
Human Motion Tracking, Face detection, NIGHT VISION, Motion Detection, People Counting, PAN-TILT, Two-way Audio, Face Recognition, Low Power
-
Function:
-
Two-way Audio, PAN-TILT, Abnormal sound detection, Alarm I/O, RESET, Built-in Mic, NIGHT VISION, Wide Angle, One-way Audio
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
UV-972-2133
-
Visible Sensor:
-
1/2.8" Progressive Scan CMOS
-
Certification:
-
ce
-
Support:
-
Onvif Protocol
-
Technology:
-
NetWork IP Camera
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
128 GB
-
Magnification:
-
33x
-
Focal Length:
-
5~180mm
-
Power:
-
DC 12V
|
Model No.
|
UV-972-2133
|
|
|
Thermal Imaging
|
|
|
|
Detector
|
|
|
|
Array format/Pixel pitch
|
640x480/17μm
|
|
|
Sensitivity
|
≤60mk@300K
|
|
|
Image Frame Rate
|
50 HZ(PAL)/60HZ(NTSC)
|
|
|
Spectral range
|
8-14μm
|
|
|
Image definition
|
768x576
|
|
|
Lens
|
100mm
|
|
|
FOV
|
8.3°x6.2°
|
|
|
Digital Zoom
|
1x，2x，4x
|
|
|
Pseudo color
|
9 Psedudo Color palettes changeable; White Hot/black hot
|
|
|
Detecting Range
|
Human:2200m
|
|
|
|
Vehicle:10000m
|
|
|
Recognition Range
|
Human:550m
|
|
|
|
Vehicle:2500m
|
|
|
Daytime Camera
|
|
|
|
Image Sensor
|
1/2.8” Progressive Scan CMOS
|
|
|
Min. Illumination
|
Color:0.0005 Lux @(F1.4,AGC ON); B/W:0.0001Lux @(F1.4,AGC ON);
|
|
|
Focal Length
|
5.5~180mm; 33x optical zoom
|
|
|
Aperture Range
|
F1.4-F4.7
|
|
|
Field of View
|
Horizontal field of view: 65.5-1.8° (wide-tele)
|
|
|
Video Compression
|
H.265 / H.264 / MJPEG
|
|
|
Resolution
|
2560 × 1440
|
|
|
BLC
|
Support
|
|
|
Exposure Mode
|
Automatic exposure/aperture priority/shutter priority/manual exposure
|
|
|
Focus Control
|
Auto focus/one-time focus/manual focus/semi-automatic focus
|
|
|
Area Exposure/Focus
|
Support
|
|
|
Defog
|
Support
|
|
|
EIS
|
Support
|
|
|
Compatibility
|
Onvif 2.4
|
|
|
Gyro stabilization
|
|
|
|
Stabilization
|
Support. 2 Axis
|
|
|
Static Accuracy
|
<0.2°RMS
|
|
|
Mode
|
ON/OFF
|
|
|
Pan/Tilt
|
|
|
|
Pan Range
|
360° (endless)
|
|
|
Pan Speed
|
0.05°/s ~ 500°/s
|
|
|
Tilt Range
|
–90° ~ +90° (auto reverse)
|
|
|
Tilt Speed
|
0.05° ~ 300°/s
|
|
|
Number of Presets
|
256
|
|
|
Patrol
|
6 patrols, up to 18 presets per patrol
|
|
|
Pattern
|
4 , with the total recording time not less than 10 mins
|
|
|
General
|
|
|
|
Power
|
DC 124V, wide voltage input； Power consumption：≤60w；
|
|
|
COM/Protocol
|
RS 422/ PELCO-D/P
|
|
|
Video Output
|
1 channel Thermal Imaging video；Network video， via Rj45
|
|
|
|
1 channel HD video；Network video， via Rj45
|
|
|
Working temperature
|
-40℃~60℃
|
|
|
Mounting
|
Mast mounting
|
|
|
Ingress Protection
|
IP67 Protection Standard
|
|
|
Weight
|
6 kg
|
|
FAQ
1. Who we are?
Hangzhou Huanyu Vision, established in 2019, is based in Zhejiang, China. We have more than 50 staff. Our market is Eastern Asia(25.00%), North America(25.00%), Western Europe(20.00%), Eastern Europe(15.00%), South Asia(5.00%).
Hangzhou Huanyu Vision, established in 2019, is based in Zhejiang, China. We have more than 50 staff. Our market is Eastern Asia(25.00%), North America(25.00%), Western Europe(20.00%), Eastern Europe(15.00%), South Asia(5.00%).
2. What warranty do we offer?
We always make a pre-production sample before mass production, and always make total and final Inspection before shipment.
3. What do we have?
Zoom camera module, Zoom camera, Camera block, Marine PTZ, IR PTZ, 4G PTZ.
4. Why can you buy from us?
More than 10-year experience in zoom camera module and PTZ design. Our factory covers an area of 2500 square meters, with 200 employees and 30 R&D engineers. We were awarded National High-tech Enterprise, Provincial R&D Center in China.
5. What services can we provide?
OEM and ODM service is available.
Deliver goods on schedule, fast delivery.
Optional shipping term: EXW, FOB, DDU.
24-hours technical support and on-line service.
