High quality industrial switch fiber ethernet 10/100M 8 ports switch 100M optical fiber 12/24/48 ports switch

High quality industrial switch fiber ethernet 10/100M 8 ports switch 100M optical fiber 12/24/48 ports switch

FOB Reference Price: Get Latest Price

≥1 Pieces

US $50

≥100 Pieces

US $45

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: HiOSO

Product name:: FOWAY1509FC

Port:: 8 100M SFP ports+1 1000M Combo uplink

MAC:: 8K

Working temperature:: -10~60℃

Storage temperature:: -40~80℃

Humidity:: 5%~90% non-condensing

Power consumption:: 7.9W

Wavelength:: 850nm/1310nm/1490nm/1550nm

Dimension:: 28mm (H)*193mm(W)*119mm (D)

Quick Details

Type:: Enterprise Switch

Model Number:: FOWAY1509FC

Place of Origin:: Guangdong, China

Brand Name:: HiOSO

Product name:: FOWAY1509FC

Port:: 8 100M SFP ports+1 1000M Combo uplink

MAC:: 8K

Working temperature:: -10~60℃

Storage temperature:: -40~80℃

Humidity:: 5%~90% non-condensing

Power consumption:: 7.9W

Wavelength:: 850nm/1310nm/1490nm/1550nm

Dimension:: 28mm (H)*193mm(W)*119mm (D)

Product Description

FOWAY1309FC
8 100M SFP + 1 Combo Uplink Fiber Switch

Feature

✔Support SFP hot swap

✔ Support DHCP, PPPoE, ACL, LLDP

✔ Support 8K MAC learning, 1Mbit storage and forward cache space, 4.6G back plane bandwidth,1632 byte large frame forwarding ✔ Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault ✔ All optic ports, strengthen the an-interference ability

✔ Metal casing design (support to hang on the wall), better for heat dissipation

Technical Specification
Parameter	Specification
Standard	IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree,IEEE802.1w Rapid STP,IEEE802.1s Multiple STP,IEEE802.1q Vlan,IEEE802.1q Qos,IEEE802.3ad Trunk,IEEE802.3X Flow Control
Wavelength	850nm/1310nm/1490nm/1550nm
Distance	100M SFP multi-mode: 2Km Single-mode: 25/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP multi-mode:220m (fiber 62.5/125μm) / 550m (fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km Cat5:100m
Port	8 100M SFP fiber ports: 100Mbps 1 Gigabit Combo port:1 Gbps, 100M/1000M SFP&10/100/1000M RJ45
MAC	8K
Buffer memory space	1Mbit
Bit error rate	<1/1000000000
MTBF	100000 hours
Power	DC12V/AC220V
Power consumption	7.9W
Working temperature	-10~60℃
Storage temperature	-40~80℃
Humidity	5%~90% non-condensing
Dimension	28mm (H)×193mm(W)×119mm (D)
