Quick Details
-
Brand Name:
-
OEM
-
Model Number:
-
LS-PS03
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Ethernet Switch poe 16ports
-
Device Type:
-
Switch - 16 Ports - Managed
-
Manufacturer:
-
Shenzhen
-
Condition:
-
100% Original Brand
-
PoE Ports:
-
1-24 Port Support PoE
-
Connector Type:
-
10/100/1000M Copper RJ-45 Ports
-
Fixed Port:
-
Lan Port
-
Applications:
-
Support PoE IP Cameras
-
Power Supply:
-
External Adpater (Input:AC100-240V 50/60Hz
-
Keywords:
-
Unmanagable Industrial poe Switch
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
1.6G
-
Brand Name:
-
OEM
-
Model Number:
-
LS-PS03
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Ethernet Switch poe 16ports
-
Device Type:
-
Switch - 16 Ports - Managed
-
Manufacturer:
-
Shenzhen
-
Condition:
-
100% Original Brand
-
PoE Ports:
-
1-24 Port Support PoE
-
Connector Type:
-
10/100/1000M Copper RJ-45 Ports
-
Fixed Port:
-
Lan Port
-
Applications:
-
Support PoE IP Cameras
-
Power Supply:
-
External Adpater (Input:AC100-240V 50/60Hz
-
Keywords:
-
Unmanagable Industrial poe Switch
•8 -Port supports 48V-56V DC power to PoE powered devices
•Extra 1-Port 10/100 Mbps UPLINK RJ-45 up to 100m
•Complies with IEEE 802.3af / 802.3at Power over Ethernet End-Span PSE
•Up to 8 IEEE 802.3af devices powered Supports PoE Power up to 15.4 watts for each PoE port, total power budget cannot be exceeded.
•Up to 8 IEEE 802.3at devices powered Supports PoE Power up to 30 watts for each PoE port, total power budget cannot be exceeded.
•120-watt PoE budget
•PoE data & power transmission distance up to 100m
•Port based VLAN for Enhanced Security
•PoE data & power transmission distance up to 250m while VLAN starts
•Excellent anti-thunder, anti-static and anti-interference ability
Product features
• IEEE 802.3af/at power on up to 24 ports
• Supply power to wireless access points and surveillance cameras over Cat-5 cabling
• 24 ×10/100/1000 Mbps Ports with AutoUplink™
• Supports PoE power up to 25.4W for each PoE port
• Supports PoE power up to 400W for all PoE ports
• Supports PoE IEEE 802.3af/at compliant PDs
• Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
• 8K entry MAC address table of the PoE Switch POE31024P with auto-learning and auto-aging
• LED indicators for monitoring power, link, activity and speed
• External power adapter supply
| Item | Description | ||
| Network Connector | Network Port | POE Ethernet Port | 1-16port:10/100Mbps |
| EthernetPort | Uplinkport:10/100Mbps | ||
| Transmission Distance | 1~16Port : 100Mbps:0~100m, 10Mbps:0~250m | ||
| UplinkPort: 0~ 100m | |||
| Transmission Medium | Cat5/5e/6standard network cable | ||
| Network Switch | Network Standard | IEEE 802.3/802.3u,IEEE 802.3x,IEEE 802.1p,IEEE 802.3az | |
| Switching Capacity | 1.6Gbps | ||
| Packet Forwarding Rate | 0.74Mpps | ||
| MAC Table | 2K | ||
| Power Over Ethernet | PoE Standard | IEEE802.3af | |
| PoE Power Supply Type | End-Span(1/2+;3/6-) | ||
| PoE Power Consumption | af=15.4W(every port) | ||
|
LED Status Indicator VLAN/Extend |
PoE Ethernet LED Indicator Indicator
|
Power: 1redlight indicates that the power normal work; | |
| POE:4 yellowlights indicate that the POE is power on; | |||
| Ethernet:6 green lights indicate that the Ethernet link and act; | |||
| Surveillance Module Light | 1pcs(Green),green indicates Camera | ||
| Environmental | Working temperature | 0℃~55℃ | |
| Relative Humidity | 20~95% | ||
| Storage temperature | -20℃~70℃ | ||
| Mechanical | |||
| Color | Black | ||
| Weight | 2000g | ||
| Stability | MTBF | >30000h | |
