The Android system version is the latest Android 13 system in the field of current automotive products.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
APM1688S
-
CPU:
-
Qualcomm 8-core
-
RAM+ROM:
-
8GB+128GB
-
WIFI:
-
802.11 A/b/g/n/ac 2.4G+5G
-
GPS:
-
Integrated Internal GPS
-
Operating System:
-
Android 13.0 OS
-
Product Type:
-
CarPlay AI Box
-
Carplay:
-
AI Box Carplay
-
Compatible car:
-
OEM Head Unit with Wired CarPlay
-
Works for:
-
Original Car Built-In CarPlay
-
NAVLYNX CarPlay AI Box Wireless Android:
-
Auto Multimedia Car Play TV Box For Netflix YouTube 4G+64G LTE GPS
Quick Details
-
Car Fitment:
-
Volkswagen, Mercedes Benz, VOLVO, Audi, PORSCHE, Honda - Europe
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
NAVLYNX
-
Model Number:
-
APM1688S
-
CPU:
-
Qualcomm 8-core
-
RAM+ROM:
-
8GB+128GB
-
WIFI:
-
802.11 A/b/g/n/ac 2.4G+5G
-
GPS:
-
Integrated Internal GPS
-
Operating System:
-
Android 13.0 OS
-
Product Type:
-
CarPlay AI Box
-
Carplay:
-
AI Box Carplay
-
Compatible car:
-
OEM Head Unit with Wired CarPlay
-
Works for:
-
Original Car Built-In CarPlay
-
NAVLYNX CarPlay AI Box Wireless Android:
-
Auto Multimedia Car Play TV Box For Netflix YouTube 4G+64G LTE GPS
Products Description
Android 13
Based on the CarPlay mobile phone side protocol, the connection with the original car OEM head unit is completed, audio and video data transmission is supported, and it supports 98% of the world's car models.
The connection is stable and reliable. If a vehicle model that cannot be connected is found, users can obtain the system log through various channels, such as online uploading or automatic capture of the memory card, and solve the vehicle model connection problem by analyzing the log.
Provide CarPlay in-car protocol app to provide customers’ mobile phones with wireless CarPlay, wireless Android Auto and MirrorLink functions to connect to the screen of the original car OEM head unit.
Car Launcher
A personalized multi-theme car launcher with handy features for your daily drive. It's designed neatly and beautiful, and the most important is very intuitive and easy to use.
Classic Dashboard with Split Screen - It applies a split screen home screen to display the 2 most important features while you drive: Maps and Media so you don't have to jump back and forth between apps. You can also easily access recently used apps from the left sidebar. You can organize your frequently used favorite apps into a tier so they remain in the bottom bar.
The system comes with a widget, which is easy to operate.
The system firmware comes with commonly used APPs by default
The system comes with Google Play by default, and users can download any Android APP they want to use.
The system is preloaded with navigation APPs, such as Google Map, Waze, etc.; audio and video APPs, such as Youtube, Netflix,Youtube Music, Spotify, VLC, etc.
The system is preloaded with navigation APPs, such as Google Map, Waze, etc.; audio and video APPs, such as Youtube, Netflix,Youtube Music, Spotify, VLC, etc.
OTA
OTA - Frequently updated versions over the air.
Product Paramenters
|
|
Ultra 1.0
|
UFO 2.0
|
Ultra 3.0
|
Rocket
|
|
Model
|
APM1688
|
APM1288S
|
APM1688S
|
APM1888
|
|
CPU
|
Snapdragon 662 (SM6115) Qualcomm octa-core processor, Cortex-A73*4 @2.0GHz + Cortex-A53*4 @1.8GHz
|
Snapdragon 665 (SM6125) Qualcomm octa-core processor, Cortex-A73*4 @2.0GHz + Cortex-A53*4 @1.8GHz
|
Snapdragon 680 (SM6225) Qualcomm octa-core processor, Cortex-A73*4 @2.4GHz + Cortex-A53*4 @1.9GHz
|
Qualcomm QCM6490 octa-core 5G SoCprocessor, Cortex-A78*1 @2.71GHz + Cortex-A78*3 @2.4GHz + Cortex-A53*4 @1.9GHz
|
|
GPU
|
Qualcomm Adreno 610
|
Qualcomm Adreno 610
|
Qualcomm Adreno 610
|
Qualcomm Adreno 643L
|
|
Memory
|
LPDDR4X-3733
|
LPDDR4X-3733
|
LPDDR4X-4266
|
LPDDR5-6400
|
|
Process
|
11 nanometers
|
11 nanometers
|
6 nanometers
|
6 nanometers
|
|
WI-FI
|
Wi-Fi 6.0 Ready
2.4GHz & 5GHz,
802.11a/b/g/n/ac/ax-ready
|
Wi-Fi 5.0
2.4GHz & 5GHz,
802.11a/b/g/n/ac
|
Wi-Fi 6.0 Ready
2.4GHz & 5GHz,
802.11a/b/g/n/ac/ax-ready
|
WIFI 6.0 Enhance
2.4GHz & 5GHz & 6GHz,
802.11a/b/g/n/ac/ax,
Support DBS, 2×2 MU-MIMO
|
|
Master BT (
Qualcomm processor internal Bluetooth
)
|
5.1
|
5.0
|
5.1
|
5.2
|
|
Slave BT (processor external onboard Bluetooth chip)
|
Realtek BTV8761, BT5.0
|
Realtek BTV8761, BT5.0
|
Realtek BTV8761, BT5.0
|
Realtek BTV8761, BT5.0
|
|
2G GSM/EDGE
|
Supported
|
Supported
|
Supported
|
Supported
|
|
3G WCDMA
|
Supported
|
Supported
|
Supported
|
Supported
|
|
4G LTE
|
Supported
|
Supported
|
Supported
|
Supported
|
|
5G SA/NSA
|
no
|
no
|
no
|
Supported
|
|
GNSS
|
Supports GPS, GLONASS, BeiDou, NavIC, Galileo positioning systems
|
Supports GPS, GLONASS, BeiDou, Galileo positioning systems
|
Supports GPS, GLONASS, BeiDou, NavIC, Galileo positioning systems
|
Supports GPS, GLONASS, BeiDou, NavIC, Galileo, QZSS and SBAS positioning systems
|
|
Storage
|
4GB+64GB or 8GB+128GB
|
4GB+64GB or 8GB+128GB
|
4GB+64GB
or 8GB+128GB
|
Only 8GB+128GB
|
|
Micro SD Card
|
card slot
|
card tray
|
card slot
|
card tray
|
|
SIM Card
|
card slot
|
card tray
|
card slot
|
card tray
|
|
Mini HDMI
|
no
|
yes
|
no
|
yes
|
|
LED
|
Blue and Red
|
Colorful Ambient Light
|
Blue and Red
|
Colorful Ambient Light
|
|
Antutu Benchmarks
|
210000
|
210000
|
300000
|
600000
|
|
CPU Process
|
11 nanometers
|
11 nanometers
|
6 nanometers
|
6 nanometers
|
|
Release date
|
Q3/2022
|
Q1/2023
|
Q4/2023
|
Q2/2023
|
|
Android Version
|
13
|
13
|
13
|
13
|
About the frequency bands of mobile networks
LTE telecommunications networks operate on a specific combination of frequency bands and bandwidth.
The following are the frequency bands supported by various NAVLYNX CarPlay AI Box models and versions in different regions. Basically it is divided into 3 versions: EAU version, NA version, and JP version.
EAU Version
:
For Europe/Asia/Australia middle East South America.
Except for North America and Japan, other regions are supported.
NA version : For North America
NA version : For North America
JP version
: For Japan
|
|
ApplePie Mini Ultra 1.0 (662)
ApplePie UFO 2.0 (665)
ApplePie Mini Ultra 3.0 (680)
|
ApplePie Rocket (6490)
|
|
EAU
(Eurasian version)
|
GSM/EDGE: 850/900/1800MHz
WCDMA: B1,B5,B8
LTE-FDD: B1,B3,B5,B7,B8,B20,B28(B28A,28B)
LTE-TDD: B38,B39,B40,B41
Hierarchical frequency bands: B1,B3,B7,B38,B39,B40,B41
|
GSM/EDGE: 900/1800 MHz
LTE: B1/B3/B5/B7/B8/B20/B28/B32/B38/B39/B40/B41/B42
LTE MIMO:
DL 4 × 4 MIMO, B1/B3/B7/B38/B40/B41/B42
5G SA/NSA:
n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78
5G MIMO:
DL 4 × 4 MIMO, n1/n3/n7/n38/n40/n41/n77/n78
UL 2 × 2 MIMO, n41/n77/n78 |
|
NA
(North American version)
|
GSM/EDGE: 850,900,1900
WCDMA: B2,B4,B5,B8 LTE-FDD: B2,B4,B5,B7,B8,B12,B13,B17,B25,B26 LTE-TDD: B38,B41(2555-2655MHz) 1. The B41 frequency band of Chinese telecom operators refers to 2555-2655MHz (100M) The B41 frequency band of US telecom operator Sprint refers to 2496-2690MHz (194M) 2. Hierarchical frequency bands: B2, B4, B7, B38, B41 |
No development yet
|
|
JP
(Japan version)
|
GSM/EDGE: 850,900,1800
WCDMA: B1,B5,B8,B19,B6 LTE-FDD: B1,B3,B5,B9,B18,B19,B26,B7,B8,B20,B28(B28A,28B) LTE-TDD: B38,B39,B40,B41 |
No development yet
|
Manufacturing Technique
Product packaging
Leadtime
|
|
Generic version
|
Logo customized
|
Software customization
|
Hardware customization
|
|
1～500
|
5
|
Negotiate
|
Negotiate
|
Negotiate
|
|
500～2000
|
15
|
Negotiate
|
Negotiate
|
Negotiate
|
|
More than 2000
|
20
|
Negotiate
|
Negotiate
|
Negotiate
|
