Quick Details
-
Productivity:
-
22M³/H
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Zoomlion
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support
-
Max. Concrete Output:
-
170/120 m3/h
-
Max. Concrete Pressure:
-
8.3/12 MPa
-
Stroke Length:
-
2100mm
-
Strokes:
-
25/18 1/min
-
Hopper Capacity:
-
600L
-
Number of Arms:
-
6
-
Hydraulic oil cooling:
-
Double fans
-
Filling height:
-
1540mm
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Peru
-
Certification:
-
ISO/CE
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
200M
-
Max. horizontal conveying distance:
-
500M
-
Productivity:
-
22M³/H
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Zoomlion
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support
-
Max. Concrete Output:
-
170/120 m3/h
-
Max. Concrete Pressure:
-
8.3/12 MPa
-
Stroke Length:
-
2100mm
-
Strokes:
-
25/18 1/min
-
Hopper Capacity:
-
600L
-
Number of Arms:
-
6
-
Hydraulic oil cooling:
-
Double fans
-
Filling height:
-
1540mm
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Peru
-
Certification:
-
ISO/CE
Zoomlion Truck Mounted Pump 50X-6RZ,50m Concrete Pump Truck
Features
• Efficient pump unit, two Rexroth main pumps gives a big output, easy to use and maintenance.
• Agile placing boom with 6 arms gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, it monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
Parameter
|
Distribution valve |
S-valve |
|
|---|---|---|
|
Max. Concrete Output |
m 3 /h |
170/120 |
|
Max. Concrete Pressure |
bar |
83/120 |
|
Delivery Cylinder |
mm |
260 |
|
Stroke Length |
mm |
2100 |
|
Strokes |
1/min |
25/18 |
|
Hopper Capacity |
L |
600 |
|
Filling height |
mm |
1540 |
|
Hydraulic System |
Open |
|
|
Hydraulic oil cooling |
Double fans |
|
|
High/Low Press. Switch |
Manual |
|
|
Lubrication on pump |
Automatic |
|
|
Lubrication on hopper |
Automatic |
|
|
GPS Data Manage |
Optional |
|
|
Boom Control Valve |
Proportional |
|
|
Number of Arms |
|
6 |
|
Folding System |
|
RZ |
|
Max. Reach Vertical |
m |
50 |
|
Max. Reach Horizontal |
m |
46 |
|
Max. Reach Depth |
m |
35.9 |
|
Min. Unfolding Height |
m |
10.7 |
|
End Hose Length |
m |
3 |
|
Pipeline |
DN125/5.5 |
|
|
Slewing Range |
±270° |
|
|
Slewing Motors |
2 motors |
|
|
Remote Control System |
Radio |
|
|
Water Pump |
20L/min, 60bar |
|
|
Tool kits with box |
Standard |
|
