Quick Details
-
Brand Name:
-
Dipower
-
Model Number:
-
24v100ah
-
Battery Size:
-
24v100, 25.6V/100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
43Kg, 43Kg
-
The charging ratio:
-
0.2C
-
The discharge rate:
-
1C
-
Electric Energy:
-
2560 Wh
-
Battery type:
-
Lifepo4 Battery
-
Warranty:
-
5 years
-
Certification:
-
CE,ICE,MSDS,UN38.3
-
Size:
-
501*482*137mm
-
Overcharge protection voltage:
-
29.2v
-
Over-discharge protection voltage:
-
21.6v
-
OEM/ODM:
-
Warmly Welcomed
Quick Details
-
Storage Type:
-
convention
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
Dipower
-
Model Number:
-
24v100ah
-
Battery Size:
-
24v100, 25.6V/100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
43Kg, 43Kg
-
The charging ratio:
-
0.2C
-
The discharge rate:
-
1C
-
Electric Energy:
-
2560 Wh
-
Battery type:
-
Lifepo4 Battery
-
Warranty:
-
5 years
-
Certification:
-
CE,ICE,MSDS,UN38.3
-
Size:
-
501*482*137mm
-
Overcharge protection voltage:
-
29.2v
-
Over-discharge protection voltage:
-
21.6v
-
OEM/ODM:
-
Warmly Welcomed
Customer praise
Detailed Images
Specification
|
Basic Parameters
|
|
Voltage
|
|
|
24V
|
|
|
|
|||||||
|
|
|
Capacity
|
|
|
100Ah(Standard )
|
|
|
|
|||||||
|
|
|
Energy
|
|
|
2.4KWh
|
|
|
|
|||||||
|
|
|
Internal resistance
|
|
|
≤150mΩ
|
|
|
|
|||||||
|
Size and weight
|
|
Height
|
|
|
137mm
|
|
|
|
|||||||
|
|
|
Width
|
|
|
482mm
|
|
|
|
|||||||
|
|
|
Length
|
|
|
501mm
|
|
|
|
|||||||
|
|
|
Weight
|
|
|
43Kg
|
|
|
|
|||||||
|
Electrical Parameters
|
|
Charging mode
|
|
|
constant current
|
|
|
|
|||||||
|
|
|
Charging Current
|
|
|
0.2C(Standard)
|
|
|
|
|||||||
|
|
|
|
|
|
1C(Maximum constant current@25℃)
|
|
|
|
|||||||
|
|
|
Overcharge protection voltage
|
|
|
29.2V
|
|
|
|
|||||||
|
|
|
Discharge mode
|
|
|
constant current
|
|
|
|
|||||||
|
|
|
Over-discharge protection voltage
|
|
|
21.6V
|
|
|
|
|||||||
|
|
|
Discharge Current
|
|
|
0.5C(Standard )
|
|
|
|
|||||||
|
|
|
|
|
|
1C(Maximum constant current@25℃)
|
|
|
|
|||||||
|
Working Parameters
|
|
Working Temperature
|
|
|
Charging (Small Current):0℃~+60℃
|
|
|
|
|||||||
|
|
|
|
|
|
Discharge(Small Current):-20℃~+55℃
|
|
|
|
|||||||
|
|
|
Storage Temperature
|
|
|
Conventional storage temperature:-5~+35℃(Three months ,SOC:20%~60%)
|
|
|
|
|||||||
|
|
|
|
|
|
Conventional storage temperature:
< 1 month:-5~+45℃ >6 months:0~+35℃ |
|
|
|
|||||||
|
|
|
Storage Humidity
|
|
|
5%~95%
|
|
|
|
|||||||
|
|
|
Transportation Environment
|
|
|
Voltage:25.6V~29.2V
|
|
|
|
|||||||
|
|
|
|
|
|
SOC:30%~60%
|
|
|
|
|||||||
|
Feature
|
|
This battery belongs to lithium iron phosphate battery. It has excellent safety performance, long life, excellent temperature
characteristics, high energy density, low cost and low pollution. |
|
|
|
|
|
|
|||||||
