Quick Details
-
Application:
-
Mall
-
Type:
-
gate operator, Gate Operators
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
TOMA
-
Model Number:
-
TM-G12B
-
mode:
-
optional
-
ODM:
-
OEM
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
graphic design
-
Application:
-
Mall
-
Type:
-
gate operator, Gate Operators
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
TOMA
-
Model Number:
-
TM-G12B
-
mode:
-
optional
-
ODM:
-
OEM
Supply voltage:24VDC,Power of motor:40W
Current:3.0A 2.5A ,Rotational speed:3200RPM
Rod's running speed:1.6cm/s,Rod's max travel:300mm
Max single-leaf length:3M,Max single-leaf weight:300Kg
Environment temperature:-20°C-+55°C,Protection class:IP44
In case of power failure,release the clutch easily,operate the gate manually.Stop acting when gate meets with obstacle
Control box:Power supply: 220VAC 50Hz/110V 60Hz,
Transformer:24V 150W,Accessories max loaded: 24VDC 500mA, Max load: 2×80W/24VDC,Environment temperature: -20°C-+55°C,
Protection fuse:10A,Running time protection: Adjustable,
Auto closing delay time: Adjustable,
Controlling single or double-leaf,Force: Adjustable is optional,
Protection class: IP55,24VDC back-up battery can be input.
