Quick Details
-
Rated Power:
-
1.5kw/2.2kw/3kw special metal use spindle
-
Engraving Speed:
-
5000mm/min
-
Main Axle Rotational Speed:
-
30000mm/min
-
Feeding Height:
-
150mm
-
Milling Cutter Diameter:
-
3.175-12.7mm
-
Application:
-
engraving metal
-
Dimensions:
-
600*600/600*900
-
Weight (KG):
-
580
-
After-sales Service Provided:
-
Video technical support
-
Key words:
-
copper cnc engraving machine
-
Spindle:
-
2.2kw Water Cooling Spindle
-
Control system:
-
NC Studio
-
Working area:
-
600*600*150mm
-
Software:
-
Artcam
-
Transmission:
-
Gear Rack
-
Color:
-
Request
-
Motor:
-
Servo Motor
-
Inverter:
-
Fuling Inverter
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Senke
-
Machine Type:
-
cnc router
-
Rated Power:
-
1.5kw/2.2kw/3kw special metal use spindle
-
Engraving Speed:
-
5000mm/min
-
Main Axle Rotational Speed:
-
30000mm/min
-
Feeding Height:
-
150mm
-
Milling Cutter Diameter:
-
3.175-12.7mm
-
Application:
-
engraving metal
-
Dimensions:
-
600*600/600*900
-
Weight (KG):
-
580
-
After-sales Service Provided:
-
Video technical support
-
Key words:
-
copper cnc engraving machine
-
Spindle:
-
2.2kw Water Cooling Spindle
-
Control system:
-
NC Studio
-
Working area:
-
600*600*150mm
-
Software:
-
Artcam
-
Transmission:
-
Gear Rack
-
Color:
-
Request
-
Motor:
-
Servo Motor
-
Inverter:
-
Fuling Inverter
Products Description
Main features:
CNC table movable, Guide rails supporting surface with high stability . Three axis with dust cover cloth structure , Ball screw & guide rails long time working with no rust . High torque spindle , high rotating speed, small rotating shaking , lower noise. With X/Y/Z axis with all square linear guide , bigger bearing redundant, longer life. Having longer life, higher precision comparing to the round guide rail . Easy operation , Humanization design, design Machine processing more handy
|
Model
|
|
|
SKM-6060
|
Size as needed
|
|||
|
X*Y*Z axis working area
|
|
|
600*600*80mm
|
Size as needed
|
|||
|
Machine frame
|
|
|
Cast iron
|
|
|||
|
Spindle power
|
|
|
1.5kw/2.2kw/3kw special metal use spindle (water cooled)
|
|
|||
|
X*Y*Z movement
|
|
|
Ball Screw/ Square rail
|
|
|||
|
Max engraving speed
|
|
|
5000mm/min
|
|
|||
|
Spindle speed
|
|
|
0-24000rpm
|
|
|||
|
Control System
|
|
|
NC-studio/DSP
|
|
|||
|
Drive Motors
|
|
|
Stepper (Servo motors & drivers optional )
|
|
|||
|
Voltage
|
|
|
220v/380v or customized
|
|
|||
|
Working Dictate
|
|
|
G-code
|
|
|||
