Quick Details
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
CETC Solar
-
Model Number:
-
NES144-7-575M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2278mmx1134mmx35mm
-
Application:
-
TOPCON 550W-575W solar panel N-Topcon solar system PV
-
Solar cell:
-
182*182mm
-
product name:
-
50 250 W Suitcase Poly 355w 350w Pv Photovoltaic Solar Home Panel
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, N-TYPE, TOPCON
-
Panel Efficiency:
-
22.26%
-
Warranty:
-
25 Years Warranty
-
Brand Name:
-
CETC Solar
-
Model Number:
-
NES144-7-575M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2278mmx1134mmx35mm
-
Application:
-
TOPCON 550W-575W solar panel N-Topcon solar system PV
-
Solar cell:
-
182*182mm
-
product name:
-
50 250 W Suitcase Poly 355w 350w Pv Photovoltaic Solar Home Panel
For 55w Panels 580 455 3000 Watt 50 250 W Suitcase Poly 355w 350w Pv Photovoltaic Solar Home Panel
For 55w Panels 580 455 3000 Watt 50 250 W Suitcase Poly 355w 350w Pv Photovoltaic Solar Home Panel
| Solar Panel Data Sheet | ||||||||
| Description of Specification | Configuration | Units | Model | |||||
| NES144-7-575M | ||||||||
| General Data | ||||||||
| Maximum Power | Pm(W) | Watts | 575W | |||||
| Watt Tolerance | Watts | 0~+5 | ||||||
| Application | DC24V | |||||||
| Storage & Operating Temperature | Deg .C | -45~85 | ||||||
| Standard Test Conditions:Cell Temperature:25 Deg. C,Irradiance:1kW/,Air Mass: 1.5 | ||||||||
| Voltage & Ampereage | ||||||||
| Maximum System Voltage | Volts | 1000VDC | ||||||
| Maximum Operating Voltage | Vmp | Volts | 42.69 | |||||
| Maximum Operating Current | Imp | Amps | 13.47 | |||||
| Open Circuit Voltage | Voc | Volts | 50.56 | |||||
| Short Circuit Current | Isc | Amps | 14.11 | |||||
| Solar Cell | ||||||||
| Cell Type and Diameter |
Monocrystalline cell 182mm |
|||||||
| Number of Cells | In Series | 144 | ||||||
| Temperatures Coefficients | ||||||||
| Temp Coefficent of Isc | Tk Isc | % per deg.C | 0.46 | |||||
| Temp Coefficent of Voc | Tk Voc | % per deg.C | -0.25 | |||||
| Temp Coefficient of Pmax | Tk Pmax | % per deg.C | -0.30 | |||||
| Normal Op. Cell Temp (NOCT) | deg.C | 45±2 | ||||||
| Materials & Accessories Data (All Certified by CE and TUV) | ||||||||
| Junction Box | IP67 rated | |||||||
| Output Cable:Wire Diameter :4m | Length | mm | 300 | |||||
| Type of Cable Connector | MC Plug Type IV | |||||||
| Frame:Aluminum Alloy | Anodized | |||||||
| Front Glass:Low Iron,High Transmisson,Tempered glass | Thickness | 3.2mm | ||||||
| Cell Encapsulation Material | EVA | mm | 0.5mm | |||||
| Backsheet Cover Material | TPT | mm | 0.3mm | |||||
| Quality Warranty (Output Power) | ||||||||
| Power Production | 90% | Years | 10 | |||||
| 80% | Years | 25 | ||||||
| Manufacturing | Years | 10 | ||||||
| Dimensions | ||||||||
| Dimensions:Length×Width×Height | mm |
2278mmx1134mmx35mm |
||||||
| Weight | kg | 28.4 | ||||||
