Quick Details
-
Mounting Type:
-
Flushed
-
Description:
-
presence sensor, occupancy sensor
-
Model Number:
-
GSA012R
-
Type:
-
presence sensor
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
GASIM
-
Theory:
-
occupancy sensor
-
Rated voltage:
-
120-277VAC 50/60Hz
-
Operating voltage:
-
108-305VAC 50/60Hz
-
Working Mode:
-
ON/OFF, 1-10V Dimming
-
Type of Load:
-
Inductive / Resistive / LED load
-
Load Capacity:
-
Inductive: 1000W /Resistive: 800w /LED load: 800w
-
Max. Surge Capacity:
-
17Arelay 50A (50% Ipeak, twidth =500uS, 230Vac full load, cold start)
-
Operating frequency:
-
5.8 GHz ±75 MHz,ISM wave band.
-
Dim down:
-
100%/50%(remote control: 100%/75%/50%/25%)
-
Detection:
-
0s/1min/3min/10min/30min/+
-
Daylight Sensor:
-
5lux~150lux/Disable(remote control)
Quick Details
-
Use:
-
presence sensor switch
-
Series:
-
Presence Sensor Switch
-
Features:
-
Lights brightness control intelligently.
-
Mounting Type:
-
Flushed
-
Description:
-
presence sensor, occupancy sensor
-
Model Number:
-
GSA012R
-
Type:
-
presence sensor
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
GASIM
-
Theory:
-
occupancy sensor
-
Rated voltage:
-
120-277VAC 50/60Hz
-
Operating voltage:
-
108-305VAC 50/60Hz
-
Working Mode:
-
ON/OFF, 1-10V Dimming
-
Type of Load:
-
Inductive / Resistive / LED load
-
Load Capacity:
-
Inductive: 1000W /Resistive: 800w /LED load: 800w
-
Max. Surge Capacity:
-
17Arelay 50A (50% Ipeak, twidth =500uS, 230Vac full load, cold start)
-
Operating frequency:
-
5.8 GHz ±75 MHz,ISM wave band.
-
Dim down:
-
100%/50%(remote control: 100%/75%/50%/25%)
-
Detection:
-
0s/1min/3min/10min/30min/+
-
Daylight Sensor:
-
5lux~150lux/Disable(remote control)
Product Description
Parameters can be adjusted by remote control, easy to install and debug.
the sensor detects human walking, minor motion(such as body movement, turn up
head and others minor movements) and breathing to realize the detection of human existence in non-sleep state.
head and others minor movements) and breathing to realize the detection of human existence in non-sleep state.
Installation Instructions
Packing & Delivery
Trade term:
EXW, FOB, CIF
MOQ : 500 pcs
Sample available：Yes
Port:China Ningbo & Shanghai
Payment: T/T, Western Union, L/C, Paypal,Trade Assurance....
Shipment: Air , Sea, Train, Express Delivery
Payment condition: 30% before production, 70% before delivery
Packing: Strong output carton box
