Quick Details
-
Case material:
-
304 stainless steel
-
Structure:
-
Frame structure/stainless steel shell/detachable
-
Working voltage:
-
AC220±10%V 50±10%HZ
-
Drive motor:
-
Brushless dc motor
-
Size:
-
1400*190*980 (mm)
-
Channel width:
-
980-1000 (mm)
-
Swing arm transmission angle:
-
180 degrees
-
Swinging direction:
-
Unidirectional or bidirectional
-
Gate opening and closing time:
-
1-2 seconds
-
Normal service life:
-
5 million times
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Rige
-
Model Number:
-
01-02
-
Case material:
-
304 stainless steel
-
Structure:
-
Frame structure/stainless steel shell/detachable
-
Working voltage:
-
AC220±10%V 50±10%HZ
-
Drive motor:
-
Brushless dc motor
-
Size:
-
1400*190*980 (mm)
-
Channel width:
-
980-1000 (mm)
-
Swing arm transmission angle:
-
180 degrees
-
Swinging direction:
-
Unidirectional or bidirectional
-
Gate opening and closing time:
-
1-2 seconds
-
Normal service life:
-
5 million times
Product Description
Case
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Brand Name
|
Rige
|
|
Case material
|
304 stainless steel
|
|
Structure
|
Frame structure/stainless steel shell/detachable
|
|
Working voltage
|
AC220±10%V 50±10%HZ
|
|
Drive motor
|
Brushless dc motor
|
|
Size
|
1400*190*980 (mm)
|
|
Channel width
|
980-1000 (mm)
|
|
Swing arm transmission angle
|
180 degrees
|
|
Swinging direction
|
Unidirectional or bidirectional
|
|
Gate opening and closing time
|
1-2 seconds
|
|
Normal service life
|
5 million times
|
|
Fire linkage function
|
Infrared 4 pairs
|
|
Work environment
|
Indoor and outdoor (shaded) -25 ℃~70 ℃ Relative humidity: ≤ 90%, non condensing
|
|
Traffic speed
|
40 people/minute (normally open), 25-30 people/minute (normally closed)
|
|
Time required to enter traffic mode after power on
|
3 seconds
|
|
Interface
|
Standard RS485 interface, distance ≤ 1200 meters
|
|
input
|
Relay switch signal or 12V level signal or 12V pulse signal with a pulse width greater than 100ms, driving current greater than
10mA |
|
Characteristic
|
1. The column is detachable, making it easy to use expansion screws for construction.
2. The motherboard is hung on the column,
making it less susceptible to water ingress and corrosion |
