Brand: Huaya Rated load: 3500kg
Ground clearance: 135mm Engine model: QUANCHAI 490
Fuel Type: Diesel Lifting Height: 3000mm (3000mm-6000mm)
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HUAYA
-
Fork Length:
-
1070mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
2700mm*1220mm*2150mm
-
Weight (KG):
-
2850 kg
-
Engine model:
-
Chinese Faw 490/yunnei 490
-
Model Number:
-
FD25
-
Tire:
-
Inflatable/solid
-
Loading Capacity:
-
3000kg
-
Item:
-
2.5 ton diesel forklift
-
Mast type:
-
2 Stage/3 Stage
-
Fork Size:
-
1070mm*125mm*50mm
-
Color:
-
Customer Demanded
-
Transmission:
-
Mechnical
-
Certification:
-
CE
Quick Details
-
Min. Lifting Height:
-
3000mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
HUAYA
-
Fork Length:
-
1070mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
2700mm*1220mm*2150mm
-
Weight (KG):
-
2850 kg
-
Engine model:
-
Chinese Faw 490/yunnei 490
-
Model Number:
-
FD25
-
Tire:
-
Inflatable/solid
-
Loading Capacity:
-
3000kg
-
Item:
-
2.5 ton diesel forklift
-
Mast type:
-
2 Stage/3 Stage
-
Fork Size:
-
1070mm*125mm*50mm
-
Color:
-
Customer Demanded
-
Transmission:
-
Mechnical
-
Certification:
-
CE
Product Description
Diesel Forklift Description:
Diesel forklifts, rated load 3 3.5 4 4.5 5 6 7 10 ton Advantages:
1. Adopt full hydraulic power steering mechanism, flexible and light steering
2. The gearbox is independent from the front axle, making maintenance more convenient
3. The oil cylinder adopts imported sealing ring to prevent oil leakage
4. Adopt a stronger gantry structure to improve the rigidity of the gantry and further improve the durability of the gantry
5. The body chassis is high, the ground clearance is large, and the passability is strong
High configuration, high performance, low fuel consumption, beautiful appearance, wide application range, etc., can provide supporting tools
Specification：
Related products
|
Model
|
FD30
|
FD35
|
FD45
|
FD50
|
|
Vehicle weight(kg)
|
4350kg
|
4560kg
|
5200kg
|
6200kg
|
|
ground clearance(mm)
|
135mm
|
135mm
|
135mm
|
175mm
|
|
Speed Full load(km/h)
|
20km/h
|
20km/h
|
20km/h
|
26km/h
|
|
Tyres Front
|
28*9-15
|
28*9-15
|
250-15
|
250-15
|
|
Tyres Rear
|
650-10
|
650-10
|
700-12
|
825-15
|
|
Mast tilting angle Front/Rear
|
6/12
|
6/12
|
6/12
|
6/12
|
|
Wheelbase(mm)
|
1700mm
|
1850mm
|
2000mm
|
2250mm
|
|
Min turning radius(mm)
|
2400mm
|
2550mm
|
2880
|
2950mm
|
|
Engine model
|
QUANCHAI 490
|
QUANCHAI 490
|
QUANCHAI 495(4C4)
|
QUANCHAI 498(4C6)
|
|
Engine power(kw)
|
37
|
37
|
42
|
65
|
|
Dimensions(mm)
|
2700*1226*2060
|
2850*1226*2060
|
2893*1300*2100
|
3195*1480*2270
|
