Quick Details
-
Size:
-
L 765mm* W 380mm* H 330m
-
Material:
-
Plated Steel
-
Warranty:
-
3 Years
-
Output Power:
-
1500W
-
Product name:
-
Automatic Car Wash Machine
-
Function:
-
Car Wash+care
-
Color:
-
Customer's Request
-
Washing System:
-
Water Spraying
-
Cleaning type:
-
Touch Free
-
Washing Speed:
-
4-10 Minutes/Car
-
Water Pressure:
-
100Kg/10Mpa
-
Water consumption:
-
90-140L/car
-
Certificate:
-
CE ISO
-
MOQ:
-
1set
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CBK
-
Model Number:
-
CBK308
-
Size:
-
L 765mm* W 380mm* H 330m
-
Material:
-
Plated Steel
-
Warranty:
-
3 Years
-
Output Power:
-
1500W
-
Product name:
-
Automatic Car Wash Machine
-
Function:
-
Car Wash+care
-
Color:
-
Customer's Request
-
Washing System:
-
Water Spraying
-
Cleaning type:
-
Touch Free
-
Washing Speed:
-
4-10 Minutes/Car
-
Water Pressure:
-
100Kg/10Mpa
-
Water consumption:
-
90-140L/car
-
Certificate:
-
CE ISO
-
MOQ:
-
1set
Products Description
|
CBK308 Function
|
|
|
|
|||
|
Chassis And Wheels Flushing
|
Automatic Chemical Mixing System
(4 Types Of Liquid)
|
Three-Dimensional Inspection
|
Voice Broadcast
|
|||
|
Indicating Parking Range
|
Frequency Conversion System
|
Security Alarm System
|
Colorful Glare
|
|||
|
Leakage Protection System
|
Intelligent Electronic Collision Avoidance
|
Mechanical Hardware Collision Avoidance
|
Car Wash Count
|
|||
|
Comes With A Frame
|
Double Layer Anti-Rust
|
Remote Control Peration
|
HMI
|
|||
|
Parameters
|
|
|
|
|||
|
Installation Size
|
L8M*W4M*H3.1M
|
Size Of Car
|
5.6M*2.6M*2.0M
|
|||
|
Power Requirement
|
15KW 380V/Customized
|
Pump Pressure
|
10MPa
|
|||
|
Standard Water Consumption
|
90-140L
|
Total Power
|
15KW+22KW
|
|||
|
Standard Chemical Liquid Consumption
|
20-150ML (Adjustable)
|
Total Weight
|
2300KG
|
|||
|
Standard Power Consumption
|
0.5-1.2 kWh
|
Shipping Volume
|
11/m3
|
|||
FAQ
1. What's the layout dimensions required for CBKWash installation ? ( Length×width×height )
CBK108:6800mm*3650mm*3000mm
CBK208: 6800mm*3800mm*3100mm
CBK308:8000mm*3800mm*3300mm
2. What is your biggest car wash size?
Our biggest car wash size is:5600mm*2600mm*2000mm
3. How long does your car washing machine take to clean a car?
Depending on the steps set in the car wash process, it takes 3-5 minutes to wash a car
CBK108:6800mm*3650mm*3000mm
CBK208: 6800mm*3800mm*3100mm
CBK308:8000mm*3800mm*3300mm
2. What is your biggest car wash size?
Our biggest car wash size is:5600mm*2600mm*2000mm
3. How long does your car washing machine take to clean a car?
Depending on the steps set in the car wash process, it takes 3-5 minutes to wash a car
