Quick Details
-
Model Number:
-
TSB-001
-
Certificate:
-
CCC/CE/ISO
-
Warranty:
-
1year
-
Product name:
-
Solar Thermal Vacuum Tube
-
Use:
-
Collect The Solar Energy
-
Color:
-
Blue/Purple/Black
-
Craft:
-
Three Target
-
Size:
-
58*1800mm/58*1920mm/58*2000mm58*2100mm
-
Liner Diameter:
-
47mm
-
Shell Diameter:
-
58mm
-
Liner Thickness:
-
Inner Tube 1.6mm
-
Shell Thickness:
-
Outer Tube 1.7mm
-
Appropriate Types:
-
Outdoor/Hotel/Garage/Commercial/Household
Quick Details
-
Pipe Material:
-
Glass
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Bessent
-
Model Number:
-
TSB-001
-
Certificate:
-
CCC/CE/ISO
-
Warranty:
-
1year
-
Product name:
-
Solar Thermal Vacuum Tube
-
Use:
-
Collect The Solar Energy
-
Color:
-
Blue/Purple/Black
-
Craft:
-
Three Target
-
Size:
-
58*1800mm/58*1920mm/58*2000mm58*2100mm
-
Liner Diameter:
-
47mm
-
Shell Diameter:
-
58mm
-
Liner Thickness:
-
Inner Tube 1.6mm
-
Shell Thickness:
-
Outer Tube 1.7mm
-
Appropriate Types:
-
Outdoor/Hotel/Garage/Commercial/Household
Specification
|
Size
|
φ58×1800mm/2100mm or as per request
|
Remarks
|
|
Material
|
High Borosilicate glass (3.3W/m.k)
|
Very high strength and also haselasticity. Three target membrane layers are Stainless Steel-AIN composite (SS-AlNx/Cu) and getter material BALL252FG
|
|
Heat absorption ratio
|
0.90
|
|
|
Hemispherical emission ratio
|
0.05
|
|
|
Stagnation Temp.
|
330ºC
|
|
|
lrradiation, H
|
4.1MJ/m²
|
|
|
Heat loss coefficient, ULT
|
0.52W/(m²·ºC)
|
|
|
Light Transmittance
|
0.92Am²
|
|
