Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Newest
-
Model Number:
-
NT3406-UV
-
Dimensions(L*W*H):
-
650*470*430mm
-
Gross Power:
-
75w
-
Weight:
-
28kg
-
Type:
-
Digital Printer
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
plastic id card printer
-
Printing Material:
-
acrylic,metal sheet,wooden board,Plexiglass,crystal
-
Ink type:
-
uv ink
-
Max.print area:
-
A4
-
Color:
-
4 color printing
-
resolution ratio:
-
2880*1440dpi
-
Ink system:
-
Continues Ink Supply System
-
Printing head:
-
90*6=540 Nozzles
-
printing thickness:
-
0-50MM
-
Print head:
-
EPSON R290
-
Certification:
-
CE Certification
Quick Details
-
Plate Type:
-
Flatbed Printer
-
Color & Page:
-
Multicolor
-
Voltage:
-
110-240V
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Newest
-
Model Number:
-
NT3406-UV
-
Dimensions(L*W*H):
-
650*470*430mm
-
Gross Power:
-
75w
-
Weight:
-
28kg
-
Type:
-
Digital Printer
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
plastic id card printer
-
Printing Material:
-
acrylic,metal sheet,wooden board,Plexiglass,crystal
-
Ink type:
-
uv ink
-
Max.print area:
-
A4
-
Color:
-
4 color printing
-
resolution ratio:
-
2880*1440dpi
-
Ink system:
-
Continues Ink Supply System
-
Printing head:
-
90*6=540 Nozzles
-
printing thickness:
-
0-50MM
-
Print head:
-
EPSON R290
-
Certification:
-
CE Certification
Factory direct sale pvc id card laser printer/3d mug printing machine/plastic id card printer
1.Application of plastic id card printer
This led uv flatbed printer is suitable for printing various plastic materials. (such as ABS,PC,PE,PP,PU,PVC,etc),acrylic,metal sheet,wooden board,Plexiglass,crystal,copper paper,tile,billboard,leather |
2.Specification of plastic id card printer
1. led uv flatbed printer Can print white color,for there have white uv ink,but if you use eco solvent ink with flatbed printer,there are no white ink,so flatbed printer can't print white color(except when we use textile ink and print on textile,for there have white textile ink)
2. led uv flatbed printer can print on any materials directly without coating,no need pretreatment,but for flatbed printer,we need spray coating before printing for almost materials,or the image will be removed very easy by scratch
3. led uv flatbed printer can print out image with Embossed Effect,but flatbed printer can't.
4. After Printing,uv ink dry immediately,but flatbed printer can't |
3.The speicifcation of plastic id card printer
Specifications | Details |
Model Number | NT3406-UV |
Ink Type | LED UV Ink |
Printer Head | EPSON R290 Printer Head,90*6=540 Nozzles |
Ink Color | C M Y K W W |
Print Size | 18*30CM |
Print Thickness | 0-50MM |
Advantage | Directly printing on all materials,no need coating,also print white as well |
Print Technology | Non-touch piezoelectric type inkjet printing |
Protection | Build with max height position,which will help us to control the height |
Up/Down | Adjust by knob,easy for operation and not easy to broken the printer head |
Print Speed |
A4 size Borderless Photo: As fast as 163 sec |
Print Weight | 0-15KG |
Ink System | CISS System,Easy for refilling ink |
Tray | Metal Tray |
Working Condition | Temperature:20°C-30°C,Humidity 40%-70% |
Print Software | PhotoPrint,Acro RIP(Windows 2000,Windows XP,Win 7 System) |
Connection | USB2.0 Port |
Power Require | 220V |
Image Format | TIFF(RGB&CMYK),BMP,PDF,EPS,JPEG,JPG Etc. |
Computer Sys | Windows XP,Windows 2000/2003/7 |
Printer Weight | 26kg(32kg with package) |
Printer Size | 650*470*430mm(with package 780*580*550mm) |
4.The Photo of plastic id card printer
