Quick Details
-
Dimension:
-
1500*1050*920mm
-
Place of Origin:
-
Zhejiang, China
-
Motor power:
-
1500W/60V
-
Battery:
-
lead acid battery,20A/12V*5PCS
-
Charging time:
-
6-8 hours
-
Transmission system:
-
chain
-
Front/rear tire:
-
19*7-8" offroad/ 18*9.5-8" offroad
-
Max Speed:
-
50km/h
-
Loading capacity:
-
65kgs
-
N.W/G.W:
-
130kgs/143 kgs
-
Certification:
-
CE
Quick Details
-
Displacement:
-
50CC
-
Brand Name:
-
BAOYUE
-
Tire Size:
-
6 inch
-
Dimension:
-
1500*1050*920mm
-
Place of Origin:
-
Zhejiang, China
-
Motor power:
-
1500W/60V
-
Battery:
-
lead acid battery,20A/12V*5PCS
-
Charging time:
-
6-8 hours
-
Transmission system:
-
chain
-
Front/rear tire:
-
19*7-8" offroad/ 18*9.5-8" offroad
-
Max Speed:
-
50km/h
-
Loading capacity:
-
65kgs
-
N.W/G.W:
-
130kgs/143 kgs
-
Certification:
-
CE
Specification
|
Item
|
HB-ATV1000I
|
|
Motor
|
1500W60V brushless motor
|
|
Controller
|
1500W60V -can adjust parameters with Bluetooth
|
|
Battery
|
60V(12V20AH lead acid battery x 5pcs)
|
|
Charging time
|
8-10 hours
|
|
Distance per charger
|
30Km
|
|
Maximum Speed
|
50Km/H
|
|
Tranmission System
|
Shaft
|
|
load Capacity
|
82kg
|
|
Grade Ability
|
10-15°
|
|
Minimum Grand Clearance
|
115±15mm
|
|
Wheelbase
|
975±20mm
|
|
Seat height
|
700±15mm
|
|
Front tire
|
19x7.0-8"
|
|
Rear tire
|
18x9.5-8"
|
|
Net/Gross weight
|
130/143/Kgs
|
|
Carton size
|
143x83x62cm
|
|
Container loading:
|
88pcs/40'HQ
|
Details Images
Large digital speedometer with powerful functions
.
Advantages
Free switching of forward gear and reverse gear.
5 speed level.
Maximum speed 45 km/h.
Advantages
brake caliper
LED taillight
