Quick Details
-
Model Number:
-
RFPV-32H
-
Model:
-
RFPV-32H
-
Standards:
-
IEC/EN60947-1IEC/EN60947-3
-
Rated insulation voltage (Ui):
-
1200V
-
Rated service voltage (Ue):
-
DC 1000V
-
Rated service current (le):
-
1A,2A,3A,4A,5A,6A,8A,10A,12A,15A,20A,25A,30A,32A
-
Rated impulse with stand voltage (Uimp):
-
6000V
-
Numbers of poles:
-
1P
-
Rated acceptable power dissipation:
-
4W
-
Rated limiting short circuit current:
-
20kA
-
Fuse dimensions:
-
10mm x 38mm
Quick Details
-
Breaking Capacity:
-
High
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LONGROAD
-
Model Number:
-
RFPV-32H
-
Model:
-
RFPV-32H
-
Standards:
-
IEC/EN60947-1IEC/EN60947-3
-
Rated insulation voltage (Ui):
-
1200V
-
Rated service voltage (Ue):
-
DC 1000V
-
Rated service current (le):
-
1A,2A,3A,4A,5A,6A,8A,10A,12A,15A,20A,25A,30A,32A
-
Rated impulse with stand voltage (Uimp):
-
6000V
-
Numbers of poles:
-
1P
-
Rated acceptable power dissipation:
-
4W
-
Rated limiting short circuit current:
-
20kA
-
Fuse dimensions:
-
10mm x 38mm
Model RFPV-32H Solar Energy DC Fuse
Productapplication
RFPV-32H Series fuse forsolar energy DC system protection is suitable for short circuit and
overload protection in distribution lines with rated voltage not exceeding DC1000V,
Rated current till to 32A and rated short circuit capacity not exceeding 20kA. Mainly
Used in solar combiner box for short circuit and overload protection of solar
Energy power generation devices and other semiconductor devices.
Productadvantage
1. ltiscomposedoffusetube,contact cap,quartz sand and fuse element.The fuse-element adoptsspotweldingprocess which ismorefirm and stableinperformance.
2. This series of fuses are compact in size,Din rail mounted, easytomount.
3. This series ofproductshave the advantagesof goodfusing characteristics,andlow powerloss.
Technical data
Overall & Installation Dimensions(mm)
FAQ
|
When can I receive your quotation and detail information after send the enquiry?
|
All your enquiry will be replied within 8 hours.
|
|
Can I get samples before place an order ?
|
Of course! We also believe that sample order is the best way to prove the quality.And in our company we offer free sample service!
Please send the enquiry to us and get the free sample!
|
|
Can you print our own logo?
|
Yes,Our company are available for OEM.
|
|
How long is the quality guarantee?
|
2-5 years warranty,our products are 100% inspection.
|
|
How long is the delivery time?
|
It usually takes about 3-5 working days for sample order,and 10-20 days for official order.
|
