Quick Details
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
QUANTUM
-
Marking Head Brand:
-
SinoGalvo
-
Weight (KG):
-
150 KG
-
Core Components:
-
fiber laser power
-
Marketing Type:
-
New Product 2024
Quick Details
-
Working Accuracy:
-
0.01mm
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Laser Type:
-
Fiber Laser
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
QUANTUM
-
Marking Head Brand:
-
SinoGalvo
-
Weight (KG):
-
150 KG
-
Core Components:
-
fiber laser power
-
Marketing Type:
-
New Product 2024
|
NO. |
Model |
MH-50FTAB-CCD |
|
1 |
Laser power |
20W/30W/50W/60W/80W100W |
|
2 |
Working area |
100*100mm/200*200mm/300*300mm |
|
3 |
Laser Wavelength |
1064nm |
|
4 |
Response time |
0.5ms |
|
5 |
Frequency of pulse |
20-100KHz |
|
6 |
Max marking depth |
≤0.5mm |
|
7 |
Marking speed |
≤7000mm/s |
|
8 |
Marking lines |
1-10 lines(in the marking area) |
|
9 |
Minimum line width |
0.1mm |
|
10 |
Minimum character |
0.15mm |
|
11 |
Repeatability accuracy |
±0.002mm |
|
12 |
Resolution ratio |
0.1mm |
|
13 |
Marking content |
Text,pattern,date,bar code,etc |
|
14 |
Operation system |
Microsoft Windows XP, Vista,7,8,10(32 and 64Bit) |
|
15 |
Control software |
EZCAD CCD Control Software |
|
16 |
Graphic format supported |
bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc. |
|
17 |
Unit power |
≤1.2KW |
|
18 |
Operation temperature |
5℃-40℃ |
|
19 |
Relative moisture |
≤ 90%,no fog |
|
20 |
Supply Voltage |
220V/50Hz/10A |
|
21 |
Machine Size |
960*870*1550mm |
|
22 |
Net Weight |
150KG |
Guarantee and After-sale service:
1. 24 months warranty for the whole machine.
2. Technical support by phone, email or WhatsApp/Skype around the clock.
3. Friendly English version manual and operation video CD disk.
4. Engineer available to service machinery overseas.
1. What's your
after-sales service?
♦ 24/7 support online.
♦ Lifelong and free technical support.
♦ We are responsible for troubleshooting.
♦ Service overseas: If the questions need to be solved face to face, we will dispatch an engineer to your company.
2. What's your
guarantee
?
♦ Laser Power Source is 100% genuine and certificate is with it.
♦ Machine is verified. Inspection and adjustments is completed as well as verified in writing.
♦ Testing is done and results is verified in writing.
3. What's your
warranty
?
♦ The complete machine warranty is two years.
4. What's your
Payment Terms
Supported?
♦ By 100% T/T in advance.
♦ By 30% T/T in advance, 70% balance paid before shipment.
♦ By Alibaba Trade Assurance, PayPal, Western Union, L/C.
5. What's your
date of delivery
?
♦ Within 7 days after receiving payment.
6. What's your
packaging
?
♦ Exported wooden case (or according to your requirements)
7. What
watt
is suitable for me?
♦ If you are not sure, please tell me what the machine will be used to do? Then I can suggest a suitable and right watt to you.
