Best Sales 3w Uv Logo Maker 5w Desktop Uv Laser Marking Machine Price For Sale

FOB Reference Price: Get Latest Price

≥1 Sets

US $5200

≥3 Sets

US $5100

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Cooling Mode:: WATER COOLING

Control Software:: EZCAD

Place of Origin:: Shandong, China

Brand Name:: LONGHUA

Weight (KG):: 100 KG

Marking Area:: 100mm*100mm/200mm*200mm/300*300mm

Product name:: Lazer Marking Machine

Laser source:: Raycus Max JPT

Model:: UV-T

laser quality:: M2<1.4mm

Laser Power:: 3W 5W

Working area:: 100*100mm/200*200mm/300*300mm

Marking Speed:: 0-5000mm/s

laser frenquency:: 20KHz~80KHz

Machine size:: 920*760*1100mm

Quick Details

Working Accuracy:: 0.01mm

Graphic Format Supported:: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP

Laser Type:: UV

Cooling Mode:: WATER COOLING

Control Software:: EZCAD

Place of Origin:: Shandong, China

Brand Name:: LONGHUA

Weight (KG):: 100 KG

Marking Area:: 100mm*100mm/200mm*200mm/300*300mm

Product name:: Lazer Marking Machine

Laser source:: Raycus Max JPT

Model:: UV-T

laser quality:: M2<1.4mm

Laser Power:: 3W 5W

Working area:: 100*100mm/200*200mm/300*300mm

Marking Speed:: 0-5000mm/s

laser frenquency:: 20KHz~80KHz

Machine size:: 920*760*1100mm

Product Parameter

Model	UV-G
Laser power	3W,5W
Max. marking size	100100mm,200200mm,300*300mm
Laser Wavelength	355nm
Control system	EZCAD
Laser quality	M2<1.2
Laser frenquency	20kHz-80kHz
Min. line width	0.013mm
Marking depth	0.01-1mm
Repetition accuracy	(+/-) 0.0001mm
Electrical requirement	AC 220V 110V / 50HZ 60HZ
Marking speed	7000mm/s-12000mm/s
Cooling system	Water cooling
Machine size	9207601100mm
Machine weight	100KG

Product details

EZCAD(JCZ) control card

* Possess the function of graph aligning, red light preview, external transmit to read date. *Being suitable for marking on the fly. *Providing hundreds of automatic marking and feeding program. *Being compatible with COREL-

DRAW, AUTOCAD, PHOTOSHOP, etc.

USA field lens

*Excellent focusing capability. *More accurate. *Improve marking quality on rough surface. *Uniform focusing spot.

Raycus laser sources

*10,0000 hours service life.

*24 hours continuous working.

*Big and famous brand, good quality.

*No need to maintain, being
suitable for hostile environment.

* Top brand in China, famous in the world, with long history, stable quality, and good customer
feedback.

* Maxphotonics, Mopa laser sources can also be provided.

24V laser power

Collimation Strip Table (GT model)

Computer suppoter

Galvo-head

*Consist of optical scanner and servo controller, adopt new technology, new material, meliorative operating principle. *Electric torsion bar replace traditional elastic material's torsion bar, greatly improve service life and reliability of long time work. *Vastly reduce delay, enhance marking speed, high repetition frequnency.

FOOT SWITCH

LIFTING HANDLE

Product Advantages

PRODUCT ADVANTAGES

*Narrow laser beam, less materials consumption, small heat affected zone. *Non-contact processing, no damage to products, no tool wear, high-quality marking. *High processing efficiency, controlled by computer, being easy to realize automation. *Processing metal and non-metal materials, especially the materials of high hardness, high melting point and brittleness. *Being qualified for bad work environment, being with very strong tolerance to dust, shock, impact, humidity and temperature.
