Quick Details
-
Brand Name:
-
TSVP
-
Model Number:
-
2XZ-0.5
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
0.18 kw
-
Outlet Size:
-
KF-16
-
Pumping speed:
-
0.5 L/S
-
Ultimate pressure:
-
1.13pa
-
Rotary speed:
-
1400r/min
-
Dimensions:
-
447mm*150mm*260mm
-
G.W./N.W:
-
17/16 kg
-
Fuel:
-
220V/380 AC Power
-
Product name:
-
vacuum Pump
-
Noise level:
-
65 dba
-
Oil capacity:
-
0.6 L
-
Certification:
-
ce
Quick Details
-
Application:
-
HVAC OEM, Pharmaceutical industry
-
Pressure:
-
1.33 Pa
-
Voltage:
-
220V/380V
-
Brand Name:
-
TSVP
-
Model Number:
-
2XZ-0.5
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
0.18 kw
-
Outlet Size:
-
KF-16
-
Pumping speed:
-
0.5 L/S
-
Ultimate pressure:
-
1.13pa
-
Rotary speed:
-
1400r/min
-
Dimensions:
-
447mm*150mm*260mm
-
G.W./N.W:
-
17/16 kg
-
Fuel:
-
220V/380 AC Power
-
Product name:
-
vacuum Pump
-
Noise level:
-
65 dba
-
Oil capacity:
-
0.6 L
-
Certification:
-
ce
Products Description
2XZ m
echanical drawing
Product Paramenters
|
Model
|
|
2XZ-0.5
|
2XZ-1
|
2XZ-2
|
2XZ-4
|
|
|
Pumping speed(L/s)
|
|
0.5
|
1
|
2
|
4
|
|
|
Ultimate Pressure(Pa)
|
Partial pressure
|
≤6×10-2
|
≤6×10-2
|
≤6×10-2
|
≤6×10-2
|
|
|
|
Total pressure
|
≤1.33
|
≤1.33
|
≤1.33
|
≤1.33
|
|
|
Rotary speed(r/min)
|
|
1400
|
1400
|
1400
|
1400
|
|
|
Rated Power马力(kw)
|
|
0.18
|
0.25
|
0.37
|
0.55
|
|
|
Power Supply电压
|
|
220/380
|
220/380
|
220/380
|
220/380
|
|
|
Connector
|
|
φ20(KF-16)
|
φ20(KF-16)
|
φ30(KF-25)
|
φ30(KF-25)
|
|
|
Noise level(db a)
|
|
65
|
65
|
66
|
68
|
|
|
Oil capacity(L)
|
|
0.6
|
0.7
|
1
|
1.2
|
|
|
Dimensions(mm)
|
|
447×150×260
|
469×150×260
|
514×168×285
|
565×168×285
|
|
|
G.W./N.W.(kg)
|
|
17/16
|
18/17
|
22/20
|
24/22
|
|
