Quick Details
-
Model Number:
-
PVDF
-
Thickness:
-
3-100MM
-
Size:
-
0.5mX1m,1mX1m,1mX2m ,customized;
-
Product name:
-
Extruded PVDF board
-
Color:
-
Natural /White
-
Density:
-
1.80g/cm3
-
Materials:
-
100% virgin material; Chinese material
-
Service:
-
cutting different size according to customer request
-
Feature:
-
Beautiful in color, easy to clean
-
Shape:
-
customised
-
Specific gravity:
-
1.78g/cm3
-
Application:
-
construction,ad,transport,Medical,the public goods etc
-
Certificate:
-
CE Approved
Quick Details
-
Processing Service:
-
Cutting, Moulding, Engraving, Printing
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Yingchuang
-
Model Number:
-
PVDF
-
Thickness:
-
3-100MM
-
Size:
-
0.5mX1m,1mX1m,1mX2m ,customized;
-
Product name:
-
Extruded PVDF board
-
Color:
-
Natural /White
-
Density:
-
1.80g/cm3
-
Materials:
-
100% virgin material; Chinese material
-
Service:
-
cutting different size according to customer request
-
Feature:
-
Beautiful in color, easy to clean
-
Shape:
-
customised
-
Specific gravity:
-
1.78g/cm3
-
Application:
-
construction,ad,transport,Medical,the public goods etc
-
Certificate:
-
CE Approved
Yingchuang high temperature and corrosion resistant PVDF pipe fittings
Regular order size: 500x1000MM/1000X1000MM /1000x2000mm
Thickness :3-100MM ( thicker thickness available)
Color: Natural / White
Packing : Standard wooden pallet / Loading in bulk
Film: Transparent protective film ( Logo customized )
PVDF is a kind of engineering plastic,with half transparent or white powder or frain appearance.The Molecular chain is very close,own doughty hydrogen bond,it contain 46% oxygen,flammability resistance,with 65%-78%rime degree,density is1.17-1.79g/cm 3, melting point is 172°C,heat distortion temperature is 112-145°C,long-term work temperature is 140-150°C.PVDF has the property of flurin resin and other general resin,except good chemical resistance,heat resistance,oxidation resistance,climate resistance,radial resistance,it also has piezoelectricity property,dielectric property and so on.
|
Item |
Test Standard |
Unit |
Value |
|
Density |
ISO1183 |
G/cm3 |
1.77 |
|
Water absorption |
DIN53495 |
% |
0.04 |
|
ISO527 |
MPa |
50 |
|
|
Tensile strength |
ISO527 |
MPa |
46 |
|
Bending strength |
ISO178 |
MPa |
80 |
|
Elasticity Strength |
ISO527 |
MPa |
2000 |
|
Impact strength(no notch) |
ISO179 |
Kj/m2 |
252 |
|
Impact strength(notch) |
ISO179 |
Kj/m2 |
22 |
|
Friction coefficient |
DIN53375 |
|
0.34 |
|
Shore Hardness |
DIN53505 |
D |
78 |
|
Flame retardant rating |
UL94 |
|
V-0 |
|
Continuous service temperature |
|
℃ |
-30-150 ℃ |
