Quick Details
-
Application:
-
Foundry Custom Lost Wax Cast Steel Precision Investment Casting
-
Item:
-
Customized Investment Casting Steel Spline Shaft With Sprocket
-
Blank Process:
-
Lost wax casting, or investment casting
-
Casting Tolerance:
-
CT7-8 for steel casting shaft coupling
-
Machining Process:
-
CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling etc.
-
Machining Tolearnce:
-
up to IT7, Ra 0.8~3.2 , according to customer requirement
-
Surface treatment:
-
Surface passivation, or as customer request
-
Quality Control:
-
FOI, IQC, IPQC, FQC from our steel casting factory
-
Package of steel casting:
-
Multiplayer wood box with big plastic bag inside
-
Service:
-
custom steel casting
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Matech Industry
-
Model Number:
-
steel casting
-
Application:
-
Foundry Custom Lost Wax Cast Steel Precision Investment Casting
-
Item:
-
Customized Investment Casting Steel Spline Shaft With Sprocket
-
Blank Process:
-
Lost wax casting, or investment casting
-
Casting Tolerance:
-
CT7-8 for steel casting shaft coupling
-
Machining Process:
-
CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling etc.
-
Machining Tolearnce:
-
up to IT7, Ra 0.8~3.2 , according to customer requirement
-
Surface treatment:
-
Surface passivation, or as customer request
-
Quality Control:
-
FOI, IQC, IPQC, FQC from our steel casting factory
-
Package of steel casting:
-
Multiplayer wood box with big plastic bag inside
-
Service:
-
custom steel casting
Foundry Custom Lost Wax Cast Steel Precision Investment Casting
|
Item Name |
Foundry Custom Lost Wax Cast Steel Precision Investment Casting |
|
General Products Application/Service Area |
Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine, transportation equipment, Valve and Pump system, Agriculture machine metal Parts, engine bracket, truck chassis bracket, gear box , gear housing , gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe, hydraulic valve , valve housing ,Fitting , flange, wheel, fly wheel, oil pump housing, starter housing, coolant pump housing, transmission shaft , transmission gear, sprocket, chains etc. |
|
Main blank Process for Steel Casting |
Investment casting (wax mold made by middle temperature wax) /Precision casting ; Lost Wax Casting (wax mold made by low temperature wax)/ Precision casting;
|
|
Blanks Tolerance -Casting Tolerance |
CT7-8 for Lost wax Casting Process CT4-6 for Investment casting Process |
|
Applicable Material for our steel casting factory |
Carbon steel, Low Carbon steel, middle carbon steel, G35, G45, WCB, WCA, WCC, ISO 340-550,
Alloy Carbon steel: G25CrMo4, Heat Resistant Steel,
Stainless Steel: CF8, CF8M, . G-X6CrNiMo1810, G-X7CrNiNb1189, SUS 304, 304L, 316, 316L.
OR According to customer requirement |
|
Casting Blank Size /Dimensions |
2 mm-600mm / 0.08inch-24inch according to customer requirement |
|
Casting Blank Weight |
Range from 0.01kg-85kg |
|
Applicable Machining Process |
CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/ Broaching/Reaming /Grinding/Honing and etc.
|
|
Machining Tolerance |
From 0.005mm-0.01mm-0.1mm |
|
Machined Surface Quality |
Ra 0.8-Ra3.2 according to customer requirement |
|
Applicable Heat Treatment |
Normalization , annealing, quenching and tempering, Case Hardening, Nitriding, Carbon Nitriding, Induction Quenching
|
|
Applicable Finish Surface Treatment |
Shot/sand blast, polishing, Surface passivation , Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting, |
|
MOQ of mass production |
For steel casting sc480: 100pcs, or as customer required For machining: 50pcs |
|
Lead Time |
45 days for Foundry Custom Lost Wax Cast Steel Precision Investment Casting |
